EUROMET FOZ800 CNC gear hobbing machine

453 640,00 zł net
No rating
Add to favorites

12 months of warranty

Contact with a trader:
Edyta Skrzypek
E-mail: edyta.skrzypek@eurometal.com.pl
Telefon: 609504408

The EUROMET FOZ800 CNC hobbing machine is a development of manual and semi-automatic machines of the FOZ series. FOZ CNC milling machines are available in versions with two (X, Y) or three (X, Y, Z) controlled axes and control systems: MITSUBISHI E60 as basic and on request FANUC or SIEMENS.

The EUROMET FOZ800 CNC hobbing machine is a development of manual and semi-automatic machines of the FOZ series. FOZ CNC milling machines are available in versions with two (X, Y) or three (X, Y, Z) controlled axes and control systems: MITSUBISHI E60 as basic and on request FANUC or SIEMENS.

Standard equipment:
  • Mitsubishi CNC control
  • CNC controlled axes X + Z or X + Y + Z
  • Tool mandrels
  • Shift wheels
  • Safety cover
  • PLC driver
  • Hydraulic system and lubrication system
  • Automatic chip conveyor
  • Air conditioning of the control cabinet
  • Equipment for installing the machine
Optional equipment (additionally payable):
  • Hydraulic automatic clamp
  • Oil cooler
  • Siemens, Fanuc control

Technical data Unit Value
Module [mm] 10
Workpiece diameter [mm] 800
Helix angle [°] +/- 45
Distance between the spindle axis and the table surface [mm] 235 - 585
Distance between the spindle axis and the table axis [mm] 50 - 550
Distance between the steady axis and the table surface [mm] 336 - 566
Table speed [rpm/min] 5,2 (10,4)
Spindle speed [rpm/min] 40 - 200
Total power [kW] 11,6/12,6
Tool dimension (diameter x length) [mm] 160x160 / 180x180
Motor power for axial travel [kW] 5,5
Z axis accelerated speed [mm/min] 900
X axis accelerated speed [mm/min] 900
Y axis accelerated speed [mm/min] 5000
Dimensions [mm] 3000x2200x2000
Weight [kg] 6500
