Gear hobbing machines
EUROMET FOZ200 CNC gear hobbing machine
Priced individually
No rating
12 months of warranty
Contact with a trader:
Krzysztof Penkowski
E-mail: krzysztof.penkowski@eurometal.com.pl
Telefon: 603 400 333
Krzysztof Penkowski
E-mail: krzysztof.penkowski@eurometal.com.pl
Telefon: 603 400 333
The EUROMET FOZ200 CNC hobbing machine is a development of manual and semi-automatic machines of the FOZ series. FOZ CNC milling machines are available in versions with two (X, Y) or three (X, Y, Z) controlled axes and control systems: MITSUBISHI E60 as basic and on request FANUC or SIEMENS.
The EUROMET FOZ200 CNC hobbing machine is a development of manual and semi-automatic machines of the FOZ series. FOZ CNC milling machines are available in versions with two (X, Y) or three (X, Y, Z) controlled axes and control systems: MITSUBISHI E60 as basic and on request FANUC or SIEMENS.
Standard equipment:
- Mitsubishi CNC control
- CNC controlled axes X + Z or X + Y + Z
- Tool mandrels
- Shift wheels
- Safety cover
- PLC driver
- Hydraulic system and lubrication system
- Automatic chip conveyor
- Air conditioning of the control cabinet
- Equipment for installing the machine
Optional equipment (additionally payable):
- Hydraulic automatic clamp
- Oil cooler
- Siemens, Fanuc control
| Technical data | Unit | Value |
|---|---|---|
| Module | [mm] | 5 |
| Workpiece diameter | [mm] | 200 |
| Helix angle | [°] | +/- 45 |
| Distance between the spindle axis and the table surface | [mm] | 260 - 490 |
| Distance between the spindle axis and the table axis | [mm] | 30 - 175 |
| Distance between the steady axis and the table surface | [mm] | 350 - 600 |
| Table speed | [rpm/min] | 20 (40) |
| Spindle speed | [rpm/min] | 80 - 400 |
| Total power | [kW] | 14,8 |
| Tool dimension (diameter x length) | [mm] | 140x180 |
| Motor power for axial travel | [kW] | 7,5 |
| Z axis accelerated speed | [mm/min] | 900 |
| X axis accelerated speed | [mm/min] | 900 |
| Y axis accelerated speed | [mm/min] | 900 |
| Dimensions | [mm] | 2400x2200x1800 |
| Weight | [kg] | 5800 |
