EUROMET SKOLAR X3 CNC milling machine (with SIEMENS 808DA control)
74 250,00 zł net
No rating
12 months of warranty
Contact with a trader:
Krzysztof Penkowski
E-mail: krzysztof.penkowski@eurometal.com.pl
Telefon: 603 400 333
Krzysztof Penkowski
E-mail: krzysztof.penkowski@eurometal.com.pl
Telefon: 603 400 333
The EUROMET SKOLAR X3 CNC milling machine (with SIEMENS 808DA control) is a small, economical CNC training machine, providing high educational values at low financial expenses. The axles are driven by high-quality stepper motors, the ribbed cast of the base provides adequate rigidity. The renowned CNC control enables the didactic process to be carried out on one of the most popular models on the market today.
Quantity
Add to cart
The EUROMET SKOLAR X3 CNC milling machine (with SIEMENS 808DA control) is a small, economical CNC training machine, providing high educational values at low financial expenses. The axles are driven by high-quality stepper motors, the ribbed cast of the base provides adequate rigidity. The renowned CNC control enables the didactic process to be carried out on one of the most popular models on the market today. The didactic machine allows you to perform all basic milling operations. Small dimensions, weight and 230V power supply enable trouble-free installation of the device almost anywhere.
Standard equipment:
- User manual in English
- MPG handwheel
- SIEMENS 808DA control
- Completely enclosed working space
- The construction of the machine is based on ribbed iron castings
- All axes driven by stepper motors
- Power 230V, 50Hz
- All axes are equipped with ball screws
- Automatic lubrication system
- Preparation for connecting the 4th axis
Optional equipment (additionally payable):
- Rotary table (4th axis)
- Set for clamping the workpiece on the table
- Chuck
- Drilling vice
- Angle vice
- Tool holder with collets
- Milling cutter starter kit
- Engraving tool kit
- Cooling system
| Technical data | Unit | Value |
|---|---|---|
| Table dimensions (length) | [mm] | 550 |
| Table dimensions (width) | [mm] | 160 |
| X axis feed range | [mm] | 280 |
| Y axis feed range | [mm] | 120 |
| Z axis feed range | [mm] | 270 |
| Spindle speed range | [rpm/min] | 100 - 5000 |
| Table load capacity | [kg] | 35 |
| Spindle taper | [-] | MT3/R8/ISO 30 |
| Accelerated feed X | [mm/min] | 2000 |
| Accelerated feed Y | [mm/min] | 2000 |
| Accelerated feed Z | [mm/min] | 2000 |
| T-slots (No. x width x spacing) | [mm] | 12x3 |
| Feed rate (X / Y / Z) | [mm/min] | 500 |
| Headstock motor power | [kW] | 1 |
| Drilling diameter | [mm] | 25 |
| Excavation | [mm] | 232 |
| Positioning accuracy | [mm] | 0,015 |
| Accuracy of re-positioning | [mm] | 0,01 |
| Device dimensions | [mm] | 1280x895x1845 |
| Machine weight | [kg] | 510 |
