The SV series machines (PINNACLE SV116 machining center - slide guides) are 3-axis vertical machining centers with a cross table that moves in the X/Y axis and a headstock that moves vertically in the Z axis. Slide guides on all axes provide high rigidity, enabling heavy-duty machining. SV series vertical machining centers can be equipped with a CNC rotary table, transforming them into 4- or even 5-axis machines.

Product description
Product parameters (See more)

The SV series machines (PINNACLE SV116 machining center - sliding guides) are 3-axis vertical machining centers with a cross table capable of X/Y movement and a headstock capable of vertical Z-axis movement. Sliding guides on all axes provide high rigidity, enabling heavy-duty machining. SV series vertical machining centers can be equipped with a CNC rotary table, transforming them into 4- or even 5-axis machines.

The machines can be equipped with gears from the renowned German brand ZF. Thanks to a wide range of accessories, the machines are suitable for both mold making and mass production. The X-axis travel of the SV series ranges from 850mm to 1400mm. The machines are available with all the most popular controls available on the market, including Fanuc, Sinumerik, and Heidenhain.

The SV series is identical to the LV series, except that the SV machines are equipped with sliding guides.

Standard equipment:

Spindle air blast
Workpiece air blast
Chip flushing
Telescopic guide guards
Automatic lubrication system
Work light
Machine status indicator
Cooling system
Compressed air and coolant gun
MPG handwheel
Electrical cabinet cooling
Rigid tapping
Chip conveyor
English user manual
CE declaration of conformity

Additional equipment:

Control system: FANUC 0i-MD/ 31i-MB, SIEMENS 828D/ 840D, FAGOR 8055i Plus, MITSUBISHI M70/ M720/ M730, HEIDENHAIN iTNC530/ TNC620
Tool magazine types: Carousel, Drum, Chain
Through-spindle cooling
Coolant tank with paper filter
Tilting rotary table (4th/5th axis controlled)
Rotary table (4th axis controlled)

Technical data	Unit	Value
Table surface (length)	[mm]	1300
Table surface (width)	[mm]	610
X axis travel	[mm]	1140
Y axis travel	[mm]	610
Z axis travel	[mm]	610
Table load	[kg]	850
T-slots (W x Pitch mm x °)	[-]	18 x 125 x 5
Distance between the spindle and the table	[mm]	110 ~ 720
Spindle taper	[-]	BT-40
Spindle speed	[rpm/min]	0 - 15000
Spindle speed (direct drive)	[rpm/min]	60 - 8000
Spindle speed (toothed belt drive)	[rpm/min]	60 - 12000
Spindle speed (gear drive)	[rpm/min]	bieg niski: 40~1750, bieg wysoki: 1751~8000
FANUC servo motor (continuous / 30min KW)	[-]	β22/3000is 3.0 (α12i/3000i 3.0)
Distance from the spindle axis to the column surface	[mm]	675
Rapid feed (X / Y / Z)	[m/min]	20 / 20 / 20
Working feed (X / Y / Z)	[m/min]	10000
The power of FANUC feed servo motors	[kW]	7.5 / 11
Tool magazine type	[-]	karuzelowy/bębnowy
Tool magazine capacity	[pcs]	24
Tool diameter	[mm]	90
Tool length	[mm]	250
Tool weight	[kg]	8
Electrical connection	[kVA]	20
Coolant tank capacity	[l]	200
Compressed air pressure	[MPa]	6
Dimensions (LxWxH)	[mm]	2950 x 3100 x 2200
Weight	[kg]	6500
