The PINNACLE DU1422 machining center enables heavy-duty milling operations. The Pinnacle DU series is designed to provide high-performance, accurate machining of complex parts with a single workpiece setup. This means reduced setup time and increased machine accuracy.

Main features of the machine:

• Movable beam structure
• High-speed 15,000 rpm spindle
• 3-axis linear scales
• Completely enclosed machining space

• The robust design ensures excellent rigidity and stability.
• High-quality Meehanite cast iron (FC30) is used.
• The beam can move vertically thanks to ball screws placed symmetrically on both sides.
• The Z axis is equipped with two linear scales to ensure synchronization between the two ball screws.
• Z-axis movement is balanced by two hydraulic cylinders combined with a chain mechanism to reduce hydraulic costs and energy consumption.
• Heavy-duty roller linear guides on 3 axes.

Standard equipment:

• Heidenhain TNC640 controller
• HR510 handwheel
• 24-station drum tool changer
• Thermally stabilized spindle with oil circulation
• Air-through tool cooling
• 3-axis feed ball screws cooled through internal channels
• Full machining area enclosure
• 3-axis linear scales
• Screw-type chip conveyor
• Chain-type chip conveyor
• Hydraulic counterbalance system on the Z axis
• Air-conditioned electrical cabinet
• Automatic lubrication system
• Cooling system
• Compressed air gun
• Coolant gun
• Work light
• Operation status light
• Set of maintenance tools
• Leveling screws and feet
