CNC machining center
EUROMET SKOLAR iX1 CNC (Sieg) machining center
32 200,00 zł net
No rating
12 months of warranty
Contact with a trader:
Krzysztof Penkowski
E-mail: krzysztof.penkowski@eurometal.com.pl
Telefon: 603 400 333
Krzysztof Penkowski
E-mail: krzysztof.penkowski@eurometal.com.pl
Telefon: 603 400 333
The EUROMET SKOLAR iX1 CNC (Sieg) machining center is a small, economical CNC machining center, providing high educational values with great financial outlays. The machine is equipped with a 4-position tool magazine. The axles are driven by high-quality stepper motors, the ribbed cast of the base provides adequate rigidity. The renowned CNC control enables the didactic process to be carried out on one of the most popular models on the market today.
Quantity
Add to cart
The EUROMET SKOLAR iX1 CNC (Sieg) machining center is a small, economical CNC machining center, providing high educational values with great financial outlays. The machine is equipped with a 4-position tool magazine. The axles are driven by high-quality stepper motors, the ribbed cast of the base provides adequate rigidity. The renowned CNC control enables the didactic process to be carried out on one of the most popular models on the market today. The machine allows you to perform all basic milling operations. Fully glazed covers enable easy observation of the machining process. Small dimensions, weight and 230V power supply enable trouble-free setting of the machine almost anywhere.
Standard equipment:
- User manual in English
- Full transparent covers of the workspace
- 4-position tool magazine
- Sieg control
- Power 230V, 50Hz
- The structure is based on ribbed iron castings
- All axes are driven by stepper motors and ball screws
- Semi-automatic lubrication system
- Preparation for the 4th axis
- CE declaration of conformity
Optional equipment (additionally payable):
- 100mm rotary table (4th axis)
- Set for fixing details on the table
- Tool holder
- Vice
- Angle vice
- Milling cutter starter kit
- Engraving tool kit
- Cooling system
- Base
| Technical data | Unit | Value |
|---|---|---|
| Table surface (length) | [mm] | 400 |
| Table surface (width) | [mm] | 145 |
| X axis travel | [mm] | 260 |
| Y axis travel | [mm] | 150 |
| Z axis travel | [mm] | 180 |
| Table load | [kg] | 20 |
| T-slots (W x Pitch mm x °) | [-] | 12 |
| Spindle taper | [-] | ISO20 |
| Spindle speed | [rpm/min] | 100 - 7000 |
| Spindle motor power | [kW] | 1000 |
| Rapid feed (X / Y / Z) | [m/min] | 2000 |
| Working feed (X / Y / Z) | [m/min] | 500 |
| Tool magazine capacity | [pcs] | 4 |
| X / Y / Z axis positioning accuracy | [mm] | 0,015 |
| A / C axis positioning accuracy | [mm] | 0,01 |
| Dimensions (LxWxH) | [mm] | 1040x860x940 |
| Weight | [kg] | 178 |
