EUROMET ECO2 5-AXIS CNC VERTICAL MACHINING CENTER
89 000,00 zł net
No rating
12 months of warranty
Contact with a trader:
Michał Bartoszuk
E-mail: michal.bartoszuk@eurometal.com.pl
Telefon: 603505252
Michał Bartoszuk
E-mail: michal.bartoszuk@eurometal.com.pl
Telefon: 603505252
The most modern technological solutions currently available on the global market are used to build ECO2 series machines, which ensures the highest quality, accuracy, speed and flexibility of processing.
Main features of the EUROMET ECO2 vertical machining center:
- Ideal for vocational training
- Compact dimensions and low weight allow for placement in a classroom
- Integrated cast bed with BC structure.
- BT30 electric spindle with automatic tool change.
- Use of high-quality ball screw and guide rail of the Taiwanese brand.
- 6-position BT30 tool magazine.
- SIEG controller (in English), simultaneous operation of 5 axes.
Standard equipment:
- RTCP
- tool length compensation
- coordinate system shift
- slope machining
| Technical data | Unit | Value |
|---|---|---|
| Table surface (length) | [mm] | 180 |
| Table surface (width) | [mm] | 180 |
| X axis travel | [mm] | 300 |
| Y axis travel | [mm] | 200 |
| Z axis travel | [mm] | 200 |
| Table load | [kg] | 25 |
| A axis rotation | [°] | 25 |
| C axis rotation | [°] | 60 |
| Spindle taper | [-] | BT30 |
| Spindle speed | [rpm/min] | 0 - 18000 |
| Spindle motor power | [kW] | 3 |
| Rapid feed (X / Y / Z) | [m/min] | 8 |
| Tool magazine capacity | [pcs] | 6 |
| Tool length | [mm] | 70 |
| Tool weight | [kg] | 3 |
| Electrical connection | [kVA] | 6,5 |
| X / Y / Z axis positioning accuracy | [mm] | 0,01 |
| Dokładność pozycjonowania osi A/C | [art-sec] | 60 |
| A / C axis positioning accuracy | [mm] | 0,01 |
| Accuracy of A / C axis re-positioning | [art-sec] | 40 |
| Dimensions (LxWxH) | [mm] | 900 x 1100 x 2000 |
| Weight | [kg] | 850 |
