SOCO SB-30x5A-3S-U CNC PIPE BENDING MACHINE

Pipe and section bending machines - with mandrel

SOCO SB-30x5A-3S-U CNC PIPE BENDING MACHINE

Priced individually

Add to favorites

12 months of warranty

Contact with a trader:
Tomasz Kierzkowski
E-mail: tomasz.kierzkowski@eurometal.com.pl
Telefon: 603505252

The new SOCO SB-30x5A-3S-U pipe bender is equipped with left- and right-side bending technology, increasing processing capabilities and minimizing interference. The new U line was created for the production of headrests for car seats, fuel lines, air conditioning and heating systems. The machine is available in two versions: 5-axis and 7-axis equipped with a DGT head.

Product description
Product parameters (See more)

Features:

Right and left side bending in one cycle
DGT bending head
5 or 7 electrically controlled axes
7-axis machine without hydraulic system
2 spindle extension speeds
Automatic spindle lubrication
CNC control with touch screen and 3D graphics
Two or three levels of bending + bending on rollers
Independent matrix for each level
Automatic pipe loading and unloading (option)
Automatic seam detection system (option)

Technical data	Unit	Value
Diameter of the bent pipe (steel)	[mm]	1.6 - 32
Diameter of the bent pipe (stainless steel)	[mm]	1 - 30
Bending radius	[mm]	120
The length of the pin	[mm]	3750
Accuracy of Y axis travel	[mm]	±0.05-0.1
B axis rotation accuracy	[°]	±0.05-0.1
C axis bending accuracy	[°]	±0.05-0.1
