SOCO SB-39 AUTO pipe bender

221 127,90 zł net
No rating
Add to favorites

12 months of warranty

Contact with a trader:
Magda Kyrcz
E-mail: magda.kyrcz@eurometal.com.pl
Telefon: 609504408

SOCO SB-39 AUTO hydraulic pipe bender equipped with a PLC controller with a touch screen. Operation is simple and intuitive, and the bending accuracy is very high.

Quantity
Add to cart

SOCO SB-39 AUTO hydraulic pipe bender equipped with a PLC controller with a touch screen. Operation is simple and intuitive, and the bending accuracy is very high.
Main features of the device:
  • PLC controller with touch screen
  • Entering data in the YBC and XYZ system
  • Possibility to convert data from XYZ to YBC
  • The operator can choose from 8 different sequences of simultaneous axes movements
  • Possibility to save up to 88 file configurations
  • Possibility to program up to 15 bends in one program
  • The machine is equipped with one bending level
  • Y and B axes (travel, rotation) controlled by servomotors with the possibility of programming the speed of each axis and the C axis controlled hydraulically
  • The machine is equipped with die holders: supporting, clamping and smoothing
  • The machine has two feed functions: a positive feed function and a multiple feed function
  • Central lubrication system for moving components and automatic spindle lubrication system
  • The control panel is placed on a movable base, enabling the most favorable positioning for the operator

Standard equipment:
  • Standard stem mounting kit
  • Hydraulic pin retraction system
  • Automatic pin lubrication system
  • Hydraulic support matrix system
  • PLC controller with touch screen
  • SOCO software installed on the machine
  • Console
  • Instructions in English
  • CE Declaration of Conformity

Technical data Unit Value
Diameter of the bent pipe (steel) [mm] 2 - 38.1
Diameter of the bent pipe (stainless steel) [mm] 1.4 - 38.1
Single travel [mm] 1800
Bending radius [mm] 200
The length of the pin [mm] 2650
Bending angle [°] 190
Bending speed [°/sec] 70
Feed speed [mm/s] 700
Bending accuracy [°] +/- 0,2
The accuracy of the positioning movements [°] +/- 0,15
Accuracy of the feed [°] +/- 0,25
Main engine power [kW] 5
Number of bends per pipe [-] 15
Pipe rotation speed [°/s] 120
Weight [kg] 1370
