IMET CUBO 350 NC FLAT automatic band saw

Band saws

IMET CUBO 350 NC FLAT automatic band saw

~~96 454,00 zł~~ 91 848,00 zł net

Add to favorites

12 months of warranty

Contact with a trader:
Krzysztof Penkowski
E-mail: krzysztof.penkowski@eurometal.com.pl
Telefon: 603 400 333

CUBO 350 NC FLAT is a numerically controlled automatic hydraulic cutter for cutting medium-sized pipes, profiles, T-sections and bars. The machine allows cutting at an angle. The integrated feeding vice with encoder ensures precise cutting length. Thanks to the Industry 4.0 Ready system, CUBO 350 NC FLAT can be controlled and programmed remotely or via touch screen.

Quantity

Model CUBO 350 NC BOX is a forefront bandsaw that provides safety to the user by protecting all the 4 sides with special design metal sheets that covers all the moving part of the bandsaw. The protection system allows full accessibility for maintenance.

Innovative and easy to user 7” touch screen display with intuitive interface to have control on all the machine settings. It’s possibile to program up 99 cutting programms and 10 different cutting length on the same bar.

CNC control gives access to all the machine operative functions: automatic calculation of the blade thickness, number of stroke repetitions and pieces that must be cut, blade speed and lowering feed rate, how many cutting length for each bar. The interface also allows to view CUBO status while working and anomalies with self-diagnosis.

Integrated feeder for automatic repetition of the cutting process. The feeder slides on hardened and chromed bar; high positioning precision due to the incremental feeding on recirculating ballscrew by self-bracking electric motor with inverter, mounted on floating plate to ease the loading of non-rectilinear bars.

The sawframe has rigid, cast-iron, IMET produced structure with tubular section that provides high resistance to strain and better performances on every sections and material. Bow is equipped with cemented and hardened endless screw and crown made in high resistance bronze alloy.

The material mechanical detect device provides for fast blade approach to the material, automatically detecting the first cut point while the end cuti s managed with a microswitch on the mobile blade guide, which allows to have perfect blade allignment thanks to the hard metal pads and supplementary bearings.

IMET automatic machines can be connected to the company network and be used remotely thanks SAWFACTORY and modem. SAWFACTORY is a dedicated software which allows to manage the cutting process from the office desk by setting cutting programs and monitoring the workflow thanks to the dedicated web app. The software also allows to also receive assistance by our technicians remotely.

	Touchscreen CUBO 350 NC FLAT is equipped with a touch screen with the ability to manage all machine functions and control the selected cutting program (up to 99 program lines can be set). Using the keyboard, you can set cutting lengths from 4-9999 mm with automatic repetition of the number of passes and the total number of cut elements.
	Cleaning the cutting band The belt is kept clean by a motorized brush. Removing chips from the interdental space increases the life of the tool.
	Feeding vice The feed takes place on the chrome-plated bars of the feeding vice. Movable handle plates make loading difficult materials easier.
	Inverter The belt speed is controlled by an inverter and a gear motor with servo ventilation. The blade can cut at speeds from 18 to 100 m/min, ensuring maximum efficiency on a variety of material grades.

Optional equipment (additionally paid):

All the automatic saws in the BS range can be connected to the company network via modem: the dedicated software SAWFACTORY is also available for teleservice, assistance, programming and remote management of the cutting process. The software allows you to transfer data and programs from the PC (where the program is created) to the machine via USB.

CUBO 350 NC (Flat and Box) are compatible with the automatic sawframe rotation device. The system has mechanical stops with 2 positions and allows to optimize user workflow with mitre cutting on a same bare in automatic cycle.

The CUBO automatic band saws (FLAT-BOX version) can be used with the bundle cutting device. The bundle cut can only be used for 0° cutting. Single piece capacity with mounted device: 350x160mm max, 55x10mm min. Cutting capacity for bundle is: max 300x160mm, minimum 85x10mm. The device can be diassembled using the 2 screws on the fixed vice and the 2 on the carriage vice and disconnecting the hydraulic tubes using the quick couplings systems. Not compatible with laser ray (only one can be put on the same machine).

It is possible to request for any machine the minimum lubrication which eliminates the dispersion of coolant typical in the use of emulsifiable oil, the duration of the blade is in no way affected.

It's available for all the CUBO SERIES bandsaw an optional motorized screw chip conveyor placed laterally (on the unload side) of the machine. The chip conveyor allows to optimize the machine efficiency by removing chips while cutting.

The device tracks the cutting line on the material during the sawframe descent. Not compabile with hydraulic bundle device (only one of the two can be put on a single machine).

Angle digital display

Connection element for roller table on the loading side.

Idle roller table compatible both for the loading and unloading side. First element, 2m in length and maximum capacity 700kg.

Idle roller table compatible for both the loading and unloading sides. Next element with 1 pedestal, 2m long and maximum capacity 600kg.

Pair of vertical steel containment rollers. Maximum 2 couples; single element 2m. To be used without rollers cover.

Technical data	Unit	Value
The width of the cutting band	[mm]	27
Vise opening width	[mm]	350
The dimensions of the cutting band	[mm]	3370x27x0.9
Cutting band speed	[m/min]	15-100
Cutting band motor power	[kW]	1.8
Working height	[mm]	880
Final waste	[mm]	80
Length of a single pass	[mm]	515
Coolant tank capacity	[l]	100
Hydraulic reservoir capacity	[l]	20
Dimensions	[mm]	1850x1900x1990
Weight	[kg]	890
