IMET CUBO 400 NC FLAT automatic band saw

Band saws

IMET CUBO 400 NC FLAT automatic band saw

101 539,00 zł net

Add to favorites

12 months of warranty

Contact with a trader:
Krzysztof Penkowski
E-mail: krzysztof.penkowski@eurometal.com.pl
Telefon: 603 400 333

CUBO 400 NC FLAT is a numerically controlled automatic hydraulic cutter for cutting medium-sized pipes, profiles, T-sections and bars. The machine allows cutting at an angle. The integrated feeding vice with encoder ensures precise cutting length. Thanks to the Industry 4.0 Ready system, CUBO 400 NC FLAT can be controlled and programmed remotely or via touch screen.

Quantity

CUBO 400 NC FLAT is an automatic bandsaw with CNC suitable to be a professional working tool for batch production for tubes, bars, profiles and solids. The machine bow rotation is manual while the automatic feeder is integrated. Thanks to INDUSTRY 4.0 READY optional, the user can control its machine remotely (or with the 7" integrated touch screen display).

Touch screen display

Automatic IMET bandsaws have touch screen display (7" in this version) that allows to manage, set and view all functioning settings with just few clicks. The interface is intuitive, simple and easy-to-use, so that the user can easilty set cutting lines and programs, have a self-diagnosis to detech errors. The CNC system allows to set up to 99 programs, 10 lengths for each bars while the cutting length range goes from 4mm to 9999mm with automatic stroke repetition.

Feeder

Machine has an integrated feeder with 515mm single stroke. The feeder is on floating plate that allows to load also not-rectilinear bars. Full stroke on tempered guides for highest positioning precision.

Positioning precision
The incremental screws provides for the highest positioning precision. The movement is provided by electric motor with inverter, econcoder and recyrculating ballscrew.

Mechanical detect device

CUBO 400 NC FLAT is equipped with a mechanical detect device for material detection while starting the cut to optimize the cutting process: the device ease the sawframe fast approach to the material, regulating also the end cut, blade penetrationa and blade rising once the process ends.

Steel sawframe

IMET bandsaws have strong and rigid steel sawframe with tubolar section to give maximum resistance while cutting. Blade allignment guaranteed by mobile hard pads blade guides. This strong structure allows to reduce vibration and bindings while cutting, increasing cutting performances.

Blade speed

Automatic bandsaws produced by Imet are standardly equipped with electronic inverter for speed variation speed that increase speed range to 18-100 m/min. BS 400/60 AFI-NC blade motor has 2.2kw power with motor reducer.

Blade 34mm

CUBO 400 NC FLAT uses a blade 34mm to optimize cutting performances and times: with this blade and its motor reducer the machines has a perfect material penetration even on bigger profiles (and solid materials up to 250mm with C45 steels).

Blade cleaning

All Imet semiautomatic and automatic machine mount as standard a motorized metal brush with nylon teeth.

Optional equipment (additionally paid):

Industry 4.0 Ready
IMET automatic machines can be connected to the company network and be used remotely thanks SAWFACTORY and modem. SAWFACTORY is a dedicated software which allows to manage the cutting process from the office desk by setting cutting programs and monitoring the workflow thanks to the dedicated web app. The software also allows to also receive assistance by our technicians remotely.

Bundle cutting device for CUBO

The CUBO automatic band saws (FLAT/BOX versione) can be used with bundle cutting device. The bundle cut can only be used for 0° cutting. Single piece capacity with mounted device: 350x160mm max, 55x10mm min. Cutting capacity for bundle is: max 300x160mm, minimum 85x10mm. The device can be diassembled using the 2 screws on the fixed vice and the 2 on the carriage vice and disconnecting the hydraulic tubes using the quick couplings systems. The device cannot be mounted on the same machine with laser ray.

Minimal lubrification system

Minimal lubrification system to avoid any coolant dispersion, keeping working area perfectly clean so that the machine can always work in the most efficient way; it works thanks to automatic switch and it has 2 nozzle and 1.3 l tank capacity.

Motorized chip conveyor

It's available for all the CUBO SERIES automatic bandsaw an optional motorized chip conveyor placed laterally (on unloading side) of the machine. The chip conveyor allows to optimize the machine efficiency by removing remainings and chips while cutting.

Automatic saw rotation with mechanical stops

CUBO 400 NC (Flat and Box) are compatible with the automatic sawframe rotation device. The system has mechanical stops with 2 positions and allows to optimize user workflow with mitre cutting on a same bare in automatic cycle.

Laser ray

To ease the working process, it's possibile to require di special laser ray that points the cutting line on the material before starting to operate. It can't be put on the same machine with hydraulic bundle device.

Angle display
It's possible to view the set angle throught a digital display on panel control.

Technical data	Unit	Value
The width of the cutting band	[mm]	34
Vise opening width	[mm]	400
The dimensions of the cutting band	[mm]	4020x34x1.1
Cutting band speed	[m/min]	18-100
Cutting band motor power	[kW]	2.2
Working height	[mm]	890
Final waste	[mm]	80
Length of a single pass	[mm]	515
Coolant tank capacity	[l]	100
Hydraulic reservoir capacity	[l]	20
Dimensions	[mm]	1850x2200x1990
Weight	[kg]	990
