Band saws

IMET BS 350 GH gravity bandsaw

41 181,00 zł net
No rating
Add to favorites

12 months of warranty

Contact with a trader:
Magda Kyrcz
E-mail: magda.kyrcz@eurometal.com.pl
Telefon: 609504408

The IMET BS 350 GH gravity cutter is a versatile and reliable machine with autonomous lowering, designed for cutting small and medium series productions, both mechanical and carpentry, for cuts at an angle of up to 45° to the right and up to 60° to the left.

Quantity
Add to cart

The IMET BS 350 GH gravity cutter is a versatile and reliable machine with autonomous lowering, designed for cutting small and medium series productions, both mechanical and carpentry, for cuts at an angle of up to 45° to the right and up to 60° to the left.

Main features:

  • arm lifting: manual
  • possibility of turning up to 45 degrees to the right and 60 degrees to the left
  • cutting band dimensions: 3370 x 27 x 0.9mm
  • vice: hand - quick clamp
  • min. motor power 1500W
  • supply voltage 400V
  • belt travel speed 35/70 m/min
  • cutting range for 0° (rectangle) 350 x h200 mm
  • cutting range for 0° (shaft, pipe) 305 mm
  • powerful 3-phase motor enabling operation at two cutting speeds: 35 and 70 m/min
  • arm, vice and base made of cast iron
  • cutting band guides with double bearings
  • motor thermal protection
  • limit switch
  • brush for cleaning the cutting band from chips
  • manometer indicating the tension of the cutting band
  • 110W engine responsible for supplying coolant
  • adjustable, hydraulic system for lowering the cutter arm

CUTTER CUTTING ANGLE

305

350x200

260

45°

250

230x200

230

60°

175

170x100

155

Standard equipment:
  • Cooling system
  • Bimetallic tape – 1 piece in the machine
  • User manual in English
  • CE certificate
Optional equipment (additionally paid):
  • Roller feeders
  • Measure with bumper
  • Connector

Technical data Unit Value
The width of the cutting band [mm] 27
Vise opening width [mm] 350
The dimensions of the cutting band [mm] 3370x27x0.9
Cutting band speed [m/min] 37/74
Cutting band motor power [kW] 1.5/1.8
Working height [mm] 940
Dimensions [mm] 1480x1700x1900
Weight [kg] 606
