IMET CUBO 300 E FLAT automatic band saw

Band saws

IMET CUBO 300 E FLAT automatic band saw

69 300,00 zł net

Add to favorites

12 months of warranty

Contact with a trader:
Krzysztof Penkowski
E-mail: krzysztof.penkowski@eurometal.com.pl
Telefon: 603 400 333

CUBO 300 E FLAT is an automatic hydraulic cutter for cutting medium-sized pipes, profiles, T-sections and bars. The machine allows cutting at an angle. The cutting length is set using a manual positioning bumper with the option of multiple passes.

Quantity

CUBO 300 E FLAT is the electronic automatic bandsaw, is an innovative working tool intended to cut medium size tube, profiles and bars. The machine allows to cut one cutting length at a time by setting the measure and the position with the manual handler with digital reading. Machine has manual rotation of the bow and automatic material feeder.

Innovative CUBO series

CUBO Series introduces a cluster of innovation about design and new functionalities: CUBO range aims to optimize our customers user experience safeguarding the security of the machine operator during the cutting process, making CUBO the ideal working tool for every professional environment and metal carpentry.

Automatic material detection

CUBO Series bandsaws has an automatic material detection system thanks to a mechanical device (position sensor) that allows the sawframe to lower quickly toward the material, detecting the automatically the start-cut point and micro-switch to control the end cut point.

Cutting length

The machine is equipped with electronic control wich manual selection of the cutting length with digital reading: after setting the required length and the number of cuts, a trim cuti is performed, then the bar is cut till the end.

Programming via keyboard

Programming of all operation by means of the keayboard: through the machine display is also possible to manage blade life and speed, pieces counter, cycle time, motor absorption and working anomalies.Through the panel control is also possible to set the number of cuts.

Feeder system

CUBO 300 E FLAT is equipped with a feeder system with floating adjustment to ease the loading of material non perfectly straight and 300 mm opening; the maximum single stoke is 515 mm while the minimum is 4 mm.

Rigid sawframe

Cutting performances are guaranteed by the cast-iron sawframe with tubolar section and high blade tension (1700 kg/cm2) that reduce the strain on the blade, helping to optimze cutting times even on bigger and wider sections.

Blade protection

A carter protect che blade, allowing to have easy access for maintentance when needed; a system with blade guides with hard pads, additional lateral bearings provides for the perfect allignment of the blade. A motorized metal brush keeps the blade clean and provide to remove any residual while working.

Optional equipment (additionally paid):

Electronic inverter for variable blade speed 19-100m/min
It is possible to require , for all Imet machines, the minimal lubrication system , it avoids the dispersion of refrigerant liquid typical in the use of emulsifiable oil, the life of the blade is not in any way affected
Two pressure reducer for hydraulic vices
Laser ray

Technical data	Unit	Value
The width of the cutting band	[mm]	27
Vise opening width	[mm]	300
The dimensions of the cutting band	[mm]	2765x27x0.9
Cutting band speed	[m/min]	35/70
Cutting band motor power	[kW]	1.5
Working height	[mm]	870
Final waste	[mm]	210
Length of a single pass	[mm]	515
Coolant tank capacity	[l]	100
Hydraulic reservoir capacity	[l]	20
Dimensions	[mm]	1940x1880x1830
Weight	[kg]	850
