Band saws
IMET BS 400 GH gravity bandsaw
43 165,00 zł net
No rating
12 months of warranty
IMET BS 400 GH gravity saw The BS 400 GH is a versatile gravity saw that is easy to use. Equipped with an autonomous lowering system (GH), the machine is an ideal tool for maintenance cutting and for small and medium series production both in the world of mechanics and carpentry. The BS 400 GH band saw can cut up to 45° on the right side and up to 60° on the left side.
Quantity
Add to cart
IMET BS 400 GH gravity saw The BS 400 GH is a versatile gravity saw that is easy to use. Equipped with an autonomous lowering system (GH), the machine is an ideal tool for maintenance cutting and for small and medium series production both in the world of mechanics and carpentry. The BS 400 GH band saw can cut up to 45° on the right side and up to 60° on the left side.
- Maximum cutting diameter: ø 310 mm
- Working feed: gravity arm drop; smooth regulation
- Arm lifting: manual
- Angle cutting: right 0° - 45° - 60°; left - 45°
- Cutting band dimensions: 4020 x 34 x 1.1mm
- Band speed: 2 cutting speeds 37/74 m/min
- Vice: manual - quick clamp
Standard equipment:
- Cooling system
- Tape cleaning brush
- Bimetallic tape – 1 piece in the machine
- User manual in English
- CE certificate
Optional equipment (additionally paid):
- Roller feeders
- Measure with bumper
- Connector
- Smooth adjustment of cutting speed: 18 – 100 m/min. (inverter)
- Oil mist lubrication system (micronizer)
- Strain gauge for precise setting of belt tension
| Technical data | Unit | Value |
|---|---|---|
| The width of the cutting band | [mm] | 34 |
| Vise opening width | [mm] | 400 |
| The dimensions of the cutting band | [mm] | 4020x34x1.1 |
| Cutting band speed | [m/min] | 37/74 |
| Cutting band motor power | [kW] | 1.5/2.2 |
| Working height | [mm] | 940 |
| Dimensions | [mm] | 1530x1787x2240 |
| Weight | [kg] | 637 |
