Band saws

IMET BS 300/60 manual cutter

20 800,00 zł net
No rating
Add to favorites

12 months of warranty

Contact with a trader:
Piotr Tymiński
E-mail: piotr.tyminski@eurometal.com.pl
Telefon: 603505252

The IMET BS 300/60 manual cutter is a manual band cutter designed for cutting medium-hard materials and for small and medium-sized productions. The machine can cut from 0° to 60° to the left.

Quantity
Add to cart

The IMET BS 300/60 manual cutter is a manual band cutter designed for cutting medium-hard materials and for small and medium-sized productions. The machine can cut from 0° to 60° to the left.

Adjustable stops
The BS 300/60 is equipped with an adjustable stop system at 0°, 45° and 60° with a graduated scale for other angles.
Blade protection
The BS 300/60 blade is protected by a hinged blade guard that allows for quick and easy blade replacement.
Saw frame cutting
IMET saws are equipped with a rigid, monoblock, cast iron cutting arc with a tubular cross-section and pulleys from 320 mm, and the blade tension is 1700 kg/cm2 with front adjustment and a control microswitch.
Front vice
Quick-lock front clamp with 130 mm high jaws and adjustable stop bar for series cutting.
Blade alignment
Blade guide with carbide inserts and front bearings for optimal blade positioning.
Utilization
Safe start using the button on the handle, operation indicator light.

Optional equipment (additionally paid
  • Minimal lubrication may be required for each machine. Minimal lubrication eliminates coolant dispersion typical of using emulsifying oil. This has no effect on the life of the blade.
  • Adapter for synchronizing the movement of RTD, RTP and saw frame.
  • Pneumatic vice with handle-controlled opening and closing.

Technical data Unit Value
The width of the cutting band [mm] 27
Vise opening width [mm] 300
The dimensions of the cutting band [mm] 2765x27x0.9
Cutting band speed [m/min] 35/70
Cutting band motor power [kW] 1.5/1.8
Working height [mm] 940
Dimensions [mm] 900x1700x1860
Weight [kg] 289
