Band saws
IMET BS 300 PLUS GH gravity bandsaw
28 398,00 zł net
No rating
12 months of warranty
Contact with a trader:
Tomasz Kierzkowski
E-mail: tomasz.kierzkowski@eurometal.com.pl
Telefon: 603505252
Tomasz Kierzkowski
E-mail: tomasz.kierzkowski@eurometal.com.pl
Telefon: 603505252
Professional gravity cutter IMET BS 300 PLUS GH with a rigid, stable structure equipped with a proven drive system. The precisely guided cutting band and the ability to cut at an angle ranging from -45° to +60° make the BS 300 PLUS GH cutter a universal workshop machine.
Quantity
Add to cart
Professional gravity cutter IMET BS 300 PLUS GH with a rigid, stable structure equipped with a proven drive system. The precisely guided cutting band and the ability to cut at an angle ranging from -45° to +60° make the BS 300 PLUS GH cutter a universal workshop machine.
The arm falls by gravity, the feed value (descent speed) is regulated by a hydraulic choke. Precise belt guidance through sintered carbide plates, a rotating console on which the machine arm is mounted, a 27 mm high cutting band and a chip removal brush ensure excellent cutting results.
The machine has a built-in cooling system.
Standard equipment:
- cooling system;
- bimetallic tape – 1 piece in the machine
- user manual in English
- CE certificate
Optional equipment (additionally paid):
- roller feeders;
- measure with bumper
- connector
- oil mist lubrication system (micronizer)
- strain gauge for precise setting of belt tension
| Technical data | Unit | Value |
|---|---|---|
| The width of the cutting band | [mm] | 27 |
| Vise opening width | [mm] | 300 |
| The dimensions of the cutting band | [mm] | 2765×27×0,9 |
| Cutting band speed | [m/min] | 35/70 |
| Cutting band motor power | [kW] | 1,8 |
| Working height | [mm] | 940 |
| Coolant tank capacity | [l] | 20 |
| Dimensions | [mm] | 1230x1700x1750 |
| Weight | [kg] | 412 |
