IMET GBS 171 ESC bandsaw
No rating
12 months of warranty
GBS 171 ESC is the bandsaw for small carpentry cuts and installers. This machine can be used in various professional contexts for small productions and cuts from 0 ° to 60 °.
Quantity
Add to cart
GBS 171 ESC is the bandsaw for small carpentry cuts and installers. This machine can be used in various professional contexts for small productions and cuts from 0 ° to 60 °.
GBS 171 ESC has a large work surface with rotation integral with the bow designed to avoid incisions on the fifth wheel for easy rotation.
The vice with adjustable guides, sliding transversely on the work surface and quick approach to the cutting material.
The bimetal blade has a size of 2035x20x0.9mm with a speed of use of between 30 and 70 meters per minute making it the ideal tool for processing steel and cast iron.
Equipment:
- bimetallic tape 1 pc. - in the machine
- bumper
- base (option at extra charge)
- English user manual
- CE certificate
| Technical data | Unit | Value |
|---|---|---|
| The width of the cutting band | [mm] | 20 |
| Vise opening width | [mm] | 170 |
| The dimensions of the cutting band | [mm] | 2035x20x0,9 |
| Cutting band speed | [m/min] | 30/80 |
| Cutting band motor power | [kW] | 1.5 |
| Dimensions | [mm] | 430x1000x500 |
| Weight | [kg] | 38 |
