The DMTG VDU650 machining center is a 5-axis machining center with an extremely high accelerated travel speed - up to 60 m/min in all axes, thanks to which the machining time is reduced to a minimum.

Product description
Product parameters (See more)

The DMTG VDU650 machining center is a 5-axis machining center with an extremely high accelerated travel speed - up to 60 m/min in all axes, thanks to which the machining time is reduced to a minimum.

Standard equipment:

Siemens 840D controller
12,000 rpm spindle with direct drive
20-position tool magazine
Oil-cooled spindle
Accelerated travel – 45 m/min in all axes
Chip conveyor
Spindle blow-by
Rigid tapping function
Compressed air gun
Cooled electrical cabinet
MPG knob
USB port
CE standard
Alarm light
Maintenance tools
User manual in English

Optional equipment (additionally paid):

Spindle 15,000 rpm
30-position tool magazine
Cooling through the spindle 2 Mpa
Renishaw TS27R tool probe
Renishaw OMP60 workpiece probe

Technical data	Unit	Value
Table surface (length)	[mm]	650
Table surface (width)	[mm]	650
X axis travel	[mm]	650
Y axis travel	[mm]	650
Z axis travel	[mm]	500
Table load	[kg]	600
A axis rotation	[°]	+/- 130
C axis rotation	[°]	360
Spindle taper	[-]	HSK-A63
Spindle speed	[rpm/min]	0 - 12000
Spindle motor power	[kW]	7,5
Rapid feed (X / Y / Z)	[m/min]	45 / 45 / 45
Working feed (X / Y / Z)	[m/min]	10
Working feed (A / C)	[rpm/min]	25
Tool magazine capacity	[pcs]	20
Tool diameter	[mm]	75 / 125
Tool length	[mm]	300
Tool weight	[kg]	8
Tool change time	[s]	6
Dimensions (LxWxH)	[mm]	2600 x 4900
Weight	[kg]	15000
