Column drilling machines

Euromet W40E TS NOVA pillar drill

26 150,00 zł net
No rating
Add to favorites


Contact with a trader:
Magda Kyrcz
E-mail: magda.kyrcz@eurometal.com.pl
Telefon: 609504408

The EUROMET W40E TS Nova pillar drill is perfect for use in production plants and workshops. An extremely durable touch screen ensures ease of use and quick access to the most important information, such as operating parameters or the operating manual. The machine ensures high efficiency and precision, among others: thanks to smooth regulation of rotational speed and automatic feed with automatic threading function.

Quantity
Add to cart

The EUROMET W40E TS Nova pillar drill is perfect for use in production plants and workshops. An extremely durable touch screen ensures ease of use and quick access to the most important information, such as operating parameters or the operating manual. The machine ensures high efficiency and precision, among others: thanks to smooth regulation of rotational speed and automatic feed with automatic threading function.

Machine Features:
  • Drilling
  • Reaming
  • Threading in automatic mode
  • Drilling
  • Automatic feed

Standard equipment:
  • 8” touch screen (allows you to control machine functions and view parameters)
  • View the machine's operating instructions from the screen
  • Drilling depth limiter
  • The table tilts +/- 45 and lowers electrically
  • Inverter (stepless speed change)
  • Workspace lighting
  • Automatic feed
  • Instructions in English
  • CE declaration
Optional equipment (paid additionally):
  • laser drilling point indicator

Technical data Unit Value
Drilling diameter [mm] 40
Threading [-] M24
Distance between the spindle axis and the column [mm] 340
Distance between the end of the spindle and the worktable [mm] 580
Distance between the end of the spindle and the base [mm] 1195
Spindle stroke [mm] 190
Working table travel [mm] 430
Angular deflection of the working table [°] ± 45
Spindle taper [-] MT4
Spindle speed range [rpm/min] 60-2600
Number of spindle feeds [-] 4
Column diameter [mm] 140
The dimension of the working surface of the table [mm] 540 x 440
The dimension of the working surface of the base [mm] 415 x 400
Voltage [V] 400
Drill feed speeds [mm/rpm] 0,1; 0,2; 0,3; 0,4
Cooling circuit electric pump (three-phase motor) [l/min] 6
Coolant pump motor power [kW] 0,13
Spindle motor power [kW] 2
Weight [kg] 565
Dimensions (L × W × H) [mm] 885 x 640 x 2230
Touch screen size [mm] 121.5 x 162 (8")
