EUROMET W30 E Economic pillar drill
15 799,00 zł net
No rating
The EUROMET W30 E Economic pillar drill is used in production plants or workshops. It is characterized by compact mechanisms and ease of use. It is intended to perform the following operations: drilling, reaming, countersinking, rough reaming and threading.
Quantity
Add to cart
The EUROMET W30 E Economic pillar drill is used in production plants or workshops. It is characterized by compact mechanisms and ease of use. It is intended to perform the following operations:
- drilling
- reaming
- drilling
- rough reaming
- threading in automatic mode
Main features of the device:
- strong construction
- table lowered and raised manually
- automatic spindle feed
- threading as standard
- speed change by shift wheels
- outdoor lighting
- coolant pump
- digital readout of spindle speed
- stepless change of spindle speed
- electric motor with stepless speed change powered by an inverter
The worktable support moves up and down and can rotate ±180º around the column. The worktable can rotate 360º on the vertical axis and tilt ±45º parallel to the support. This allows for wider use with simple operation.
A special application is drilling at an angle while maintaining high drilling parameters with the possibility of machining parts in a wide range of dimensions, made of various materials. The solidly made, durable spindle also allows you to perform milling work.
Standard equipment:
- 45° tilting table
- table raised/lowered manually
- coolant pump
- lighting
- automatic feed
- inverter
- digital readout of spindle speed
- threading
- Chuck
- base with T-slots
- machine manual in English
- CE declaration of conformity
Optional equipment (additionally paid):
- automatic lubrication system
- cross table
- laser drilling point indicator
| Technical data | Unit | Value |
|---|---|---|
| Drilling diameter | [mm] | 30 |
| Threading | [-] | M20 |
| Distance between the spindle axis and the column | [mm] | 280 |
| Distance between the end of the spindle and the worktable | [mm] | 650 |
| Distance between the end of the spindle and the base | [mm] | 1120 |
| Spindle stroke | [mm] | 125 |
| Working table travel | [mm] | 605 |
| Angular deflection of the working table | [°] | +/- 45 |
| Spindle taper | [-] | Morse (No. 3) |
| Number of spindle speeds | [-] | 40 - 495 |
| Spindle speed range | [rpm/min] | 495-3500 |
| Number of spindle feeds | [-] | 3 |
| Spindle feed stroke | [mm/rpm] | 0,1; 0,2; 0,3 |
| Column diameter | [mm] | 110 |
| The dimension of the working surface of the table | [mm] | 450x380 |
| The dimension of the working surface of the base | [mm] | 335x340 |
| T-slot for base and table | [mm] | 2-T14, 2-T12 |
| Cooling circuit electric pump (three-phase motor) | [l/min] | 20 |
| Coolant pump motor power | [kW] | 0,18 |
| Spindle motor power | [kW] | 1,1 |
| Weight | [kg] | 320 |
| Dimensions (L × W × H) | [mm] | 785 x 480 x 2035 |
