SOCO SB-32x7A-2SV-U CNC pipe bending machine
585 077,85 zł net
No rating
12 months of warranty
SOCO SB-32x7A-2SV-U CNC pipe bender equipped with left- and right-side bending technology that increases processing capabilities and minimizes interference. The new U line was created for the production of headrests for car seats, fuel lines, air conditioning and heating systems. The machines come in two versions: 5-axis and 7-axis equipped with a DGT head.
Quantity
Add to cart
SOCO SB-32x7A-2SV-U CNC pipe bender equipped with left- and right-side bending technology that increases processing capabilities and minimizes interference. The new U line was created for the production of headrests for car seats, fuel lines, air conditioning and heating systems. The machines come in two versions: 5-axis and 7-axis equipped with a DGT head.
Features:
- Right and left side bending in one cycle
- DGT bending head
- 5 or 7 electrically controlled axes
- 7-axis machine without hydraulic system
- 2 spindle extension speeds
- Automatic spindle lubrication
- CNC control with touch screen and 3D graphics
- Two or three levels of bending + bending on rollers
- Independent matrix for each level
- Automatic pipe loading and unloading (option)
- Automatic seam detection system (option)
| Technical data | Unit | Value |
|---|---|---|
| Diameter of the bent pipe (steel) | [mm] | 1.6 - 32 |
| Diameter of the bent pipe (stainless steel) | [mm] | 1 - 30 |
| Bending radius | [mm] | 120 |
| The length of the pin | [mm] | 3750 |
| Accuracy of Y axis travel | [mm] | ±0.05-0.1 |
| B axis rotation accuracy | [°] | ±0.05-0.1 |
| C axis bending accuracy | [°] | ±0.05-0.1 |
