UNIVERSAL LATHE EUROMET VD800X2000

Priced individually
No rating
Add to favorites

12 months of warranty

Contact with a trader:
Piotr Tymiński
E-mail: piotr.tyminski@eurometal.com.pl
Telefon: 603505252

The EUROMET VD800x2000 universal lathe is the largest conventional lathe in the VD series. The machine is designed for low-volume production in tool shops and maintenance plants. The cast iron base plate guarantees very good machine rigidity. Increased dimensions allow machining of larger details.

The EUROMET VD800x2000 universal lathe is the largest conventional lathe in the VD series. The machine is designed for low-volume production in tool shops and maintenance plants. The cast iron base plate guarantees very good machine rigidity. Increased dimensions allow machining of larger details.

  • the bed base is made of cast iron - one element
  • hardened bed guides
  • heat-treated spindle nose
  • hardened change gears in the spindle gear
  • accelerated feed
  • central lubrication
  • the full range of threads can be machined
  • feed selection lock: by a screw or by a shaft
  • large opening in the spindle 105 mm
  • removable bridge

Equipment of the offered lathe:
  • 3-jaw lathe chuck 315 mm
  • 4-jaw chuck 400 mm
  • driving disc
  • steady rest
  • follow rest indicator for threads
  • reduction sleeve MT 7/5
  • fixed tusk MT 5
  • cooling system
  • lighting
  • accelerated feed
  • ruler for turning cones
  • digital readout for 3 axes
  • inverter
  • CE declaration of conformity
  • user manual in English

Technical data Unit Value
Turning diameter over bed [mm] 800
Turning diameter over cross slide [mm] 570
Turning diameter in the bridge [mm] 1035
Turning length [mm] 2000
Bed width [mm] 400
Spindle flight [mm] 105
Turning length in the bridge [mm] 250
Upper sled travel [mm] 230
Cross slide travel [mm] 420
Spindle tip [-] D1-8
Spindle seat [-] Morse 5
Spindle speed range [rpm/min] 16 - 1500
Maximum tool dimensions [mm] 25x25
Longitudinal feed range [mm/rpm] 0,044 - 1,48
Cross travel range [mm/rpm] 0,022 - 0,74
Metric thread [mm] 0,45 - 120
Inch thread [-] 7/16-80 T.P.I.
Modular thread [-] 0,25-60 M.P.
Thread D.P. [-] 7/8-160 D.P.
Tailstock sleeve diameter [mm] 90
Extend the tailstock quill [mm] 235
Tailstock sleeve tip [-] No.5 Morse
Engine power [kW] 7,5
Coolant pump power [kW] 0,09
Dimensions [mm] 3210x3710x4710
Weight [kg] 3345
