UNIVERSAL LATHE EUROMET VD560X1500
75 000,00 zł net
No rating
12 months of warranty
Contact with a trader:
Krzysztof Penkowski
E-mail: krzysztof.penkowski@eurometal.com.pl
Telefon: 603 400 333
Krzysztof Penkowski
E-mail: krzysztof.penkowski@eurometal.com.pl
Telefon: 603 400 333
The EUROMET VD560X1500 universal lathe is designed to work in production plants, tool shops and maintenance departments. The distinguishing features of the construction are: one-element base made of cast iron, hardened bed guides, heat-treated spindle tip.
Quantity
Add to cart
The EUROMET VD560X1500 universal lathe is designed to work in production plants, tool shops and maintenance departments. The distinguishing features of the construction are: one-element base made of cast iron, hardened bed guides, heat-treated spindle tip.
The lathe enables the processing of a full range of threads, it also has a feed lock: by a screw or shaft, a removable bridge, infinitely adjustable spindle revolutions with the possibility of setting a constant cutting speed.
An innovative solution in the VD series lathes is the use of an inverter for smooth adjustment of the spindle speed (2 ranges; low and high revolutions) cooperating with a controller that allows you to program a constant cutting speed.
Standard equipment:
- 3-jaw 315mm lathe chuck
- 4-jaw 400mm lathe chuck
- driving disc
- steady rest
- follow rest
- thread indicator
- reduction sleeve MT 6/4
- fixed tusk MT 4
- digital readouts for 3 axes
- constant cutting speed controller
- cooling system
- ruler for cones
- lighting
- User manual in English
- CE declaration of conformity
Optional equipment (paid additionally):
- Removable bridge
- The base of the bed is made of cast iron - one element
- Hardened bed guides
- Heat-treated spindle tip
- Hardened shift wheels in the spindle gear
- Possibility of machining a full range of threads
- Feed selection lock: by screw or shaft
| Technical data | Unit | Value |
|---|---|---|
| Turning diameter over bed | [mm] | 560 |
| Turning diameter over cross slide | [mm] | 305 |
| Turning diameter in the bridge | [mm] | 75 |
| Turning length | [mm] | 1500 |
| Bed width | [mm] | 350 |
| Spindle flight | [mm] | 80 |
| Turning length in the bridge | [mm] | 170 |
| Upper sled travel | [mm] | 130 |
| Spindle tip | [-] | D1-8 |
| Spindle seat | [-] | Morse 7 |
| Spindle speed range | [rpm/min] | 25 - 1600 |
| Maximum tool dimensions | [mm] | 25x25 |
| Longitudinal feed range | [mm/rpm] | 0,059 - 1,646 |
| Przesuw poprzeczny | [mm] | 326 |
| Cross travel range | [mm/rpm] | 0,02 - 0,573 |
| Metric thread | [mm] | 0,2 - 14 |
| Inch thread | [-] | 2-112 T.P.I. |
| Modular thread | [-] | 0,1-7 M.P. |
| Thread D.P. | [-] | 4-112 D.P. |
| Tailstock sleeve diameter | [mm] | 75 |
| Extend the tailstock quill | [mm] | 180 |
| Tailstock sleeve tip | [-] | No.5 Morse |
| Engine power | [kW] | 7,5 |
| Coolant pump power | [kW] | 0,1 |
| Dimensions | [mm] | 2390x1150x1430 |
| Weight | [kg] | 2335 |
