UNIVERSAL LATHE EUROMET D660X1500
67 500,00 zł net
No rating
12 months of warranty
Contact with a trader:
Krzysztof Penkowski
E-mail: krzysztof.penkowski@eurometal.com.pl
Telefon: 603 400 333
Krzysztof Penkowski
E-mail: krzysztof.penkowski@eurometal.com.pl
Telefon: 603 400 333
The EUROMET D660x1500 universal lathe is designed for low-volume production in tool shops and maintenance plants. The cast iron base plate guarantees very good machine rigidity. Increased dimensions allow machining of larger details.
Instrukcja obsługi: tokarka uniwersalna EUROMET D660X1500
Add to cart
150,00 zł
* applies to instructionQuantity
Add to cart
The EUROMET D660x1500 universal lathe is designed for low-volume production in tool shops and maintenance plants. The cast iron base plate guarantees very good machine rigidity. Increased dimensions allow machining of larger details.
- removable bridge
- the bed base is made of cast iron - one element
- hardened bed guides
- heat-treated spindle nose
- hardened change gears in the spindle gear
- accelerated feed
- central lubrication
- the full range of threads can be machined
- feed selection lock: by a screw or by a shaft
- large opening in the spindle 105 mm
Standard equipment:
- 3-jaw lathe chuck 315mm
- 4-jaw 400mm lathe chuck
- driving disc
- steady rest
- steady rest
- thread indicator
- digital readout for 2 axes
- reduction sleeve MT 6/4
- fixed tusk MT 4
- cooling system
- lighting
- accelerated feed
- user manual in English
- CE declaration of conformity
Optional equipment (paid additionally):
- quick-change holder
- ruler for cones
- digital readout for 3 axes
| Technical data | Unit | Value |
|---|---|---|
| Turning diameter over bed | [mm] | 660 |
| Turning diameter over cross slide | [mm] | 440 |
| Turning diameter in the bridge | [mm] | 900 |
| Turning length | [mm] | 1500 |
| Bed width | [mm] | 400 |
| Spindle flight | [mm] | 105 |
| Turning length in the bridge | [mm] | 250 |
| Spindle tip | [-] | D1-8 |
| Spindle seat | [-] | Morse 5 |
| Spindle speed range | [rpm/min] | 26 - 1700 |
| Maximum tool dimensions | [mm] | 25x25 |
| Longitudinal feed range | [mm/rpm] | 0,044 - 1,48 |
| Cross travel range | [mm/rpm] | 0,022 - 0,74 |
| Metric thread | [mm] | 0,45 - 120 |
| Inch thread | [-] | 7/16-80 T.P.I. |
| Modular thread | [-] | 0,25-60 M.P. |
| Thread D.P. | [-] | 7/8-160 D.P. |
| Tailstock sleeve diameter | [mm] | 90 |
| Extend the tailstock quill | [mm] | 235 |
| Tailstock sleeve tip | [-] | No.5 Morse |
| Engine power | [kW] | 7,5 |
| Coolant pump power | [kW] | 0,09 |
| Dimensions | [mm] | 3200x1250x1840 |
| Weight | [kg] | 2700 |
