Didactic lathes

THE EUROMET SKOLAR I6S MACHINE (WITH SIEG CONTROL)

59 300,00 zł net
No rating
Add to favorites

12 months of warranty

Contact with a trader:
Piotr Tymiński
E-mail: piotr.tyminski@eurometal.com.pl
Telefon: 603505252

The EUROMET SKOLAR i6S machine (with SIEG control) is a small, economical CNC lathe with an inclined bed, providing high educational values with low financial outlays. The axles are driven by high-quality stepper motors, the ribbed cast of the bed provides adequate rigidity. The renowned CNC control enables the didactic process to be carried out on one of the most popular models on the market today. The machine is equipped with an 8-position tool head. The machine allows you to perform all basic turning operations such as machining cylindrical, conical, internal and external surfaces, planning, cutting, threading, etc. Small dimensions, weight and 230V power supply enable trouble-free setting of the machine almost anywhere.

Quantity
Add to cart

The EUROMET SKOLAR i6S machine (with SIEG control) is a small, economical CNC lathe with an inclined bed, providing high educational values with low financial outlays. The axles are driven by high-quality stepper motors, the ribbed cast of the bed provides adequate rigidity. The renowned CNC control enables the didactic process to be carried out on one of the most popular models on the market today. The machine is equipped with an 8-position tool head. The machine allows you to perform all basic turning operations such as machining cylindrical, conical, internal and external surfaces, planning, cutting, threading, etc. Small dimensions, weight and 230V power supply enable trouble-free setting of the machine almost anywhere.

Standard equipment:
  • Sieg control
  • 8 position automatic tool head
  • Slanted bed
  • High-quality stepper motors
  • Precise linear guides
  • Power supply 230V / 50Hz
  • CE declaration of conformity
  • User manual in English

Technical data Unit Value
Control [-] SIEG
Power [kW/Hz] 1500
Flight over the bed [mm] 300
Turning length in centers [mm] 400
Spindle speed range [rpm/min] 100 - 3000
Spindle taper [-] MT3
X axis travel [mm] 240
Z axis travel [mm] 320
X / Z axis accelerated feed rates [mm/min] 5000
X / Z axis working feed speed [mm/min] 1000
Tailstock cone [-] MT2
Tailstock sleeve diameter [mm] 17
Tailstock quill extension [mm] 50
Number of tool sockets [pcs] 8
Positioning accuracy [mm] 0,005
Chuck diameter [mm] 125
Accuracy of re-positioning [mm] 0,005
X-axis motor torque [Nm] 400
Z axis motor torque [Nm] 400
Dimensions [mm] 1400x770x1600
Weight [kg] 620
