Swing-Beam hydraulic guillotines

EUROMET HGS 4x2000 NC hydraulic guillotine shears (swing-beam system)

71 890,00 zł net
No rating
Add to favorites

12 months of warranty

Contact with a trader:
Piotr Tymiński
E-mail: piotr.tyminski@eurometal.com.pl
Telefon: 603505252

Hydrauliczne nożyce gilotynowe EUROMET HGS 4x2000 NC posiadają regulację szczeliny między nożami, regulację tylnego zderzaka z odczytem cyfrowym, regulację długości zejścia noża, licznik cięć. Dzięki podnoszonemu zderzakowi istnieje możliwość cięcia arkusza blachy na przestrzał maszyny. Maszyna posiada oświetlenie linii cięcia. Nożyce gilotynowe typu „swing beam” (nóż górny zainstalowany na wahliwej belce), nadaje się do cięcia blachy stalowej jak również z metali kolorowych.

Quantity
Add to cart

EUROMET HGS 4x2000 NC hydraulic guillotine shears have an adjustment of the gap between the knives, adjustment of the rear bumper with digital readout, adjustment of the knife descent length, and a cut counter. Thanks to the raised bumper, it is possible to cut sheet metal across the machine. The machine has cutting line lighting.
Swing beam guillotine shears (upper knife installed on a swinging beam), suitable for cutting steel sheets as well as non-ferrous metals.
The simple design of the machine ensures failure-free operation. The machine is suitable for all production plants as well as for small workshops.

Standard equipment:
  • Rear bumper powered by an electric motor
  • Digital reading of the rear bumper position,
  • Adjusting the gap between knives,
  • set of knives,
  • Ball guidance of the sheet metal on the table,
  • 3 front supports,
  • Front bumper with measure,
  • Side safety covers,
  • Rear safety cover,
  • Illuminated cutting line
  • Foot switch
  • Electrical parts from ABB, Siemens and Mitsubishi
  • User manual in English
  • CE Declaration of Conformity

Optional equipment (additionally paid):
  • Rear bumper on ball screws
  • CNC control with touch screen (controlled: rear bumper position, gap between knives, upper knife descent length)
  • NC control for 1 axis - rear bumper

Technical data Unit Value
Cutting thickness [mm] 4
Cutting width [mm] 2000
The number of beats per minute [-] 18
Table height [mm] 740
Engine power [kW] 4
The spacing of the side walls [mm] 2150
The angle between the cutting edges [°] 1° 30'
The length of the knives [mm] 2050
Dimensions [mm] 2550 x 1430 x 1560
Weight [kg] 3500
