EUROMET HGS 20x3200 NC hydraulic guillotine shears (swing-beam system)
182 313,00 zł net
No rating
12 months of warranty
Contact with a trader:
Krzysztof Penkowski
E-mail: krzysztof.penkowski@eurometal.com.pl
Telefon: 603 400 333
Krzysztof Penkowski
E-mail: krzysztof.penkowski@eurometal.com.pl
Telefon: 603 400 333
EUROMET HGS 20x3200 NC hydraulic guillotine shears have an adjustment of the gap between the knives, adjustment of the rear bumper with digital readout, adjustment of the knife descent length, and a cut counter. Thanks to the raised bumper, it is possible to cut sheet metal across the machine. The machine has cutting line lighting.
Quantity
Add to cart
EUROMET HGS 20x3200 NC hydraulic guillotine shears have an adjustment of the gap between the knives, adjustment of the rear bumper with digital readout, adjustment of the knife descent length, and a cut counter. Thanks to the raised bumper, it is possible to cut sheet metal across the machine. The machine has cutting line lighting.
Swing beam guillotine shears (upper knife installed on a swinging beam), suitable for cutting steel sheets as well as non-ferrous metals.
The simple design of the machine ensures failure-free operation. The machine is suitable for all production plants as well as for small workshops.
WStandard equipment:
- Rear bumper powered by an electric motor
- Digital reading of the rear bumper position,
- Adjusting the gap between knives,
- set of knives,
- Ball guidance of the sheet metal on the table,
- 3 front supports,
- Front bumper with measure,
- Side safety covers,
- Rear safety cover,
- Illuminated cutting line
- Foot switch
- Electrical parts from ABB, Siemens and Mitsubishi
- User manual in English
- CE Declaration of Conformity
Optional equipment (paid additionally):
- Rear bumper on ball screws
- CNC control with touch screen (controlled: rear bumper position, gap between knives, upper knife descent length)
- NC control for 1 axis - rear bumper
| Technical data | Unit | Value |
|---|---|---|
| Cutting thickness | [mm] | 20 |
| Cutting width | [mm] | 3200 |
| The number of beats per minute | [-] | 5 |
| Table height | [mm] | 860 |
| Engine power | [kW] | 37 |
| The spacing of the side walls | [mm] | 3550 |
| The angle between the cutting edges | [°] | 2° 30' |
| The length of the knives | [mm] | 3300 |
| Dimensions | [mm] | 4100 x 2350 x 2710 |
| Weight | [kg] | 25000 |
