Manual circular saw RECORD 350 is a strong, reliable working too, suitable to cut up to 45° and left right and 90° on the longitudinal axes are also possible thanks to rotating vice. It can cut profiles, tubes, pipes and solids (70 kg/mm²) so that it can be useful in many working environments like mechanic workshops, metal carpentry and tooling shops. RECORD is very easy to use thanks to the start-stop button on the handler and easy rotating system throught a dedicated lever, double material clamping with closing jaws and antiburr device. To increase angle setting process and have a better positioning, the machine has an adjustable easy stops system at 0° and 45°.
Standard equipment:
- equipped with a standard anti-burr and adjustable bar stop for making cuts in series
- bronze wheel / endless screw in oil bath with adjustable bearings and elastic coupling
- the start button of RECORD 350 is located in the handle
- screw clamp with quick locking and adjustable guides; a special lever makes it swivel and removable.
- equipped with a system of adjustable stops at 0 ° and 45 ° on a graduated scale on the support surface
Optional equipment (additionally paid):
- a double vice with 160mm opening
- pneumatic vice (opening/closing synchronized with the movement of the head)
- bar support with adjustable height from 710 to 1100 mm (capacity 150 kg)
- IBL floor stand
