Circular saws

IMET RECORD 350 circular saw

17 200,00 zł net
No rating
Add to favorites

12 months of warranty

Contact with a trader:
Piotr Tymiński
E-mail: piotr.tyminski@eurometal.com.pl
Telefon: 603505252

IMET RECORD 350 circular saw is a robust and reliable machine for cutting metals (steel with a resistance of 70kg / m2). Equipped with swivel head and vice, it makes cuts from 0 ° to 45 ° to the right and left, also allowing cutting to 90 ° along the longitudinal axis.

Quantity
Add to cart

Manual circular saw RECORD 350 is a strong, reliable working too, suitable to cut up to 45° and left right and 90° on the longitudinal axes are also possible thanks to rotating vice. It can cut profiles, tubes, pipes and solids (70 kg/mm²) so that it can be useful in many working environments like mechanic workshops, metal carpentry and tooling shops. RECORD is very easy to use thanks to the start-stop button on the handler and easy rotating system throught  a dedicated lever, double material clamping with closing jaws and antiburr device. To increase angle setting process and have a better positioning, the machine has an adjustable easy stops system at 0° and 45°.

Standard equipment:

  • equipped with a standard anti-burr and adjustable bar stop for making cuts in series
  • bronze wheel / endless screw in oil bath with adjustable bearings and elastic coupling
  • the start button of RECORD 350 is located in the handle
  • screw clamp with quick locking and adjustable guides; a special lever makes it swivel and removable.
  • equipped with a system of adjustable stops at 0 ° and 45 ° on a graduated scale on the support surface
Optional equipment (additionally paid):
  • a double vice with 160mm opening
  • pneumatic vice (opening/closing synchronized with the movement of the head)
  • bar support with adjustable height from 710 to 1100 mm (capacity 150 kg)
  • IBL floor stand

Technical data Unit Value
The diameter of the cutting disc [mm] 350
Vise opening width [mm] 160
Disc bore diameter [mm] 32
Cutting disc speed [rpm/min] 30/60
Cutting disc motor power [kW] 1.8 / 2.5
Coolant tank capacity [l] 40
Dimensions [mm] 600x1200x1060
Weight [kg] 206
