Didactic CNC machining centers

EUROMET SKOLAR iX3 CNC machining center

68 000,00 zł net
No rating
Add to favorites

12 months of warranty

Contact with a trader:
Krzysztof Penkowski
E-mail: krzysztof.penkowski@eurometal.com.pl
Telefon: 603 400 333

The EUROMET SKOLAR iX3 CNC machining center is a small, economical CNC machining center, providing high educational values at low financial costs. The machine is equipped with a 12-position tool magazine, significantly increasing functionality. The axes are driven by high-quality stepper motors, the ribbed cast base ensures appropriate stiffness. The renowned CNC control enables the teaching process to be carried out on one of the most popular models currently on the market.

Quantity
Add to cart

The EUROMET SKOLAR iX3 CNC machining center is a small, economical CNC machining center, providing high educational values at low financial costs. The machine is equipped with a 12-position tool magazine, significantly increasing functionality. The axes are driven by high-quality stepper motors, the ribbed cast base ensures appropriate stiffness. The renowned CNC control enables the teaching process to be carried out on one of the most popular models currently on the market. The machine allows you to perform all basic milling operations. Fully glazed covers enable trouble-free observation of the machining process. Small dimensions, weight and 230V power supply allow you to easily place the machine in almost any place.

Standard equipment:
  • CE Declaration of Conformity
  • A small, economical machining center that ensures high machining accuracy at low costs.
  • 12-position tool magazine
  • Transparent covers of the processing space enable trouble-free observation of the ongoing process
  • High-class stepper motors
  • Manual lubrication system
  • SIEMENS 808DA control
  • Power supply 230V/50HZ
  • User manual in English
Optional equipment (additionally paid):
  • Additional equipment:
  • Rotary table 4th axis
  • MPG knob
  • Set for mounting details on the table
  • Vice
  • Starter toolkit
  • Cooling system
  • Base

Technical data Unit Value
Drilling diameter [mm] 16
Worktable size (length) [mm] 550
Worktable size (width) [mm] 160
T-slot width [mm] 12
Number of T-slots [-] 3
Table load [kg] 35
X axis travel [mm] 280
Y axis travel [mm] 150
Z axis travel [mm] 270
X / Y axis motor torque [Nm] 400
Z axis motor torque [Nm] 750
Number of tools [-] 12
X / Y / Z axis accelerated feed [mm/min] 3000
Working feed of the X / Y / Z axis [mm/min] 2000
Recess [mm] 1000
Positioning accuracy [mm] 0,015
Accuracy of re-positioning [mm] 0,01
Spindle taper [-] ISO 20
Rotation speed [rpm/min] 100 - 5000
Spindle motor power [W] 1000
Dimensions [mm] 1280x895x1845
Weight [kg] 510
