KENT USA KGS 1224 SD1 automatic surface grinder

109 273,00 zł net
No rating
Add to favorites

12 months of warranty

Contact with a trader:
Magda Kyrcz
E-mail: magda.kyrcz@eurometal.com.pl
Telefon: 609504408

KENT USA KGS 1224 SD1 automatic surface grinding machine equipped with a Siemens PLC controller and a Siemens servomotor responsible for controlling the vertical travel of the headstock (Z axis). Automatic vertical feed of 0.001-0.1mm/pass and 0.01 pitch for transverse feed (Y-axis) provide the ability to perform rough grinding, finishing and sparking in one work cycle. Z axis ball screw - Taiwanese production, Y axis ball screw - Chinese production.

Quantity
Add to cart

The KENT USA KGS 1224 SD1 automatic surface grinder uses the Siemens + MPG PLC controller and is a machine with the ability to program a full cycle of detail grinding. Extended versions of KGS AHS grinders, equipped with a touch control panel, are available in two basic versions:
KGS SD1 - Grinding machine equipped with a PLC controller and a servomotor responsible for controlling the vertical travel of the headstock. Automatic vertical feed of 0.001-0.1mm/pass provides the ability to perform rough grinding, finishing and sparking out in one work cycle.
KGS SD2 - Grinding machine equipped with two servo motors that operate the vertical feed of the headstock and the transverse feed of the working table. Thanks to the automatic transverse feed with the possibility of a precise feed of 0.001mm/pass, it is possible to precisely grind the vertical edges of the detail, grooves or grooves.
Each KGS grinder, equipped with a hydraulic drive for longitudinal travel of the working table, can be available in the SD1 or SD2 version.
Small workpieces may be less well held by an electromagnetic table with a standard pitch. In order to ensure proper holding of small workpieces, an electromagnetic table with a smaller pitch (option) should be used.

Standard equipment:
  • Grinding wheel
  • Rear guard
  • Magnetic table
  • PLC controller with Siemens touch panel
  • MPG knob
  • Vertical and transverse feed ball screw
  • Vertical and cross feed servo motor
  • Static wheel balancer
  • CE declaration of conformity
  • User manual in English
Optional equipment (additionally payable):
  • Sustaining the table's operation in the event of a power failure - UPS
  • Device for parallel dressing of the grinding wheel
  • Device for dressing the grinding wheel at an angle
  • Basic magnetic separator
  • Magnetic separator with coolant pump and paper filter

Technical data Unit Value
The width of the table [mm] 300
Table length [mm] 600
Longitudinal feed [mm] 660
Cross feed [mm] 370
Distance from the table surface to the spindle axis [mm] 540
Maximum table load [kg] 420
T-slot for table clamping [mm] 1 x 14
Table speed [m/min] 5 - 25
Transverse travel per 1 division of the vernier scale [mm] 0,02
Transverse travel per revolution of the wheel [mm] 5
Transverse automatic feed per cut (SD1) [mm] 0,5 – 12
Transverse automatic feed per cut (SD2) [mm] 0,001/0,01/0,1
Accelerated cross feed [mm/min] 790
Grinding wheel size [mm] 355 x 40 x 127
Spindle rotation [rpm/min] 0 - 1450
Feed per revolution of the MGP wheel [-] x1, x10, x100
Minimal automatic vertical feed [mm] 0,001
Main engine power [kW] 4
Hydraulic pump motor power [kW] 2,2
Coolant pump motor power [W] 90
Cross feed motor power [W] 90
Floor area occupied [mm] 2600 x 2500
Weight [kg] 1910
