Hole grinding machines
JG3S Ø 6-200mm hole grinder
Priced individually
No rating
12 months of warranty
Contact with a trader:
Tomasz Kierzkowski
E-mail: tomasz.kierzkowski@eurometal.com.pl
Telefon: 603505252
Tomasz Kierzkowski
E-mail: tomasz.kierzkowski@eurometal.com.pl
Telefon: 603505252
JG3S hole grinders, thanks to their high accuracy, make it easy to find the optimal process for the workpiece. These machines automatically grind internal and external diameters, faces and cones.
JG3S hole grinders, thanks to their high accuracy, make it easy to find the optimal process for the workpiece. These machines automatically grind internal and external diameters, faces and cones.
FANUC controller and self-developed JIMATIC F-9000 grinding software. Perfect twenty workpiece grinding routines at one time, including internal and face surfaces etc., for large capacity, simple grinding, high efficiency and high accuracy.
- Taiwanese cnc hole grinding machine
- High efficiency and precision
- CNC control system
Standard equipment:
- Fanuc 0i-tf controller, JIMATIC-F9000 software (Fanuc system)
- X and Z axis servo motor
- Ball screws in the X and Z axis
- Hydraulic pressure lubrication system
- Diamond dresser φ10 * 35l
- Magnetic coolant separator
- Splash guard φ340
- Grinding spindle (belt) 90-250l (10,000 rpm)
- Belt and pulley (30 * 913, φ190)
- Inverter (Yaskawa) (3hp)
- Grinding wheel motor (3hp)
- Paper filter and pump (250l)
- LED work light
- Tool box with a set of maintenance tools
- Leveling adjusting screw and base
- Full cover with oil mist collector
- Warning lighting
- CE declaration of conformity
- User manual in English
Optional equipment (additionally payable):
- Hydraulic 3-jaw chuck
- Oil mist lubrication
- 9 ”3-jaw chuck
| Technical data | Unit | Value |
|---|---|---|
| Swing diameter over the table | [mm] | 300 |
| Grinding depth | [mm] | 200 |
| Internal grinding range | [mm] | 6 - 200 |
| External grinding range | [mm] | 150 |
| Outer diameter of the workpiece to be machined | [mm] | 150 |
| Length of external grinding | [mm] | 250 |
| Workpiece length | [mm] | 250 |
| Load on the spindle head | [kg] | 90 |
| Spindle speed | [rpm/min] | 1 - 900 |
| Inner hole taper | [-] | MT5 |
| Through hole diameter | [mm] | 32 |
| Swivel of the headstock | [°] | -5~+25 |
| Feed in the X axis | [mm] | 200 |
| Feed in the Z axis | [mm] | 250 |
| Minimum feed value | [mm] | 0.001 |
| Automatic infeed speed | [mm/min] | 5000 |
| Voltage | [V] | 200(60Hz) |
| Device dimensions (LxWxH) | [mm] | 1600 |
| Weight | [kg] | 2150x1620x1370 |
