MACKMA BTW75 volumetric briquetting machine

Compacting metal chips

MACKMA BTW75 volumetric briquetting machine

423 529,00 zł net

Add to favorites

12 months of warranty

Contact with a trader:
Magda Kyrcz
E-mail: magda.kyrcz@eurometal.com.pl
Telefon: 609504408

The MACKMA BTW75 volumetric briquetting machine is suitable for the most durable materials. The material is loaded by gravity and the resulting briquettes will be the same size with millimeter precision.

Quantity

The MACKMA BTW75 volumetric briquetting press is suitable for the most durable materials. The material is loaded by gravity and the resulting briquettes will be the same size with millimeter precision. The volumetric briquette press has two briquette outputs, which means more briquettes can be produced, and the machine also has a more powerful hydraulic pump and a stronger piston.

The working principle of the volumetric machine is as follows: When compressing one briquette, the other chamber will be loaded with new material to compress the new briquette while returning to the starting position.

A machine designed for compacting metal chips from mechanical processing.

Different types of savings related to:

automatic cycle processing without the presence of a human for chip processing
recovery of plant area originally intended for waste storage
reuse of coolant recovered from the briquetting press
ease of use
little space requirement
possibility of adapting to various types of surface layout
machinable materials: all materials with machining residues (steel, aluminum, brass, filings, grinding sludge, etc.)
areas of application: mechanical and industrial processing in many sectors

User manual in English

Technical data	Unit	Value
Briquette diameter	[mm]	75
Max. briquette length	[mm]	75
Aluminum production	[kg/h]	1 - 200
Steel production	[kg/h]	1 - 400
Engine power	[kW]	6
Voltage	[V]	380/400
Energy consumption per hour	[kW]	1,2
Power supply	[Hz]	50
Double acting hydraulic piston	[-]	tak
Number of cycles per minute	[-]	6
Oil tank	[l]	100
External oil drain and regeneration tank	[-]	opcja
Radiator with double oil temperature control	[-]	tak
Internal performance hydraulic pump	[l/min]	80
Built-in vibration tank	[-]	tak
Additional chip mixer	[-]	tak
Built-in long chip shredder	[-]	opcja
Tank capacity	[l]	700
The machine is open on 3 sides for internal inspection	[-]	tak
Start/stop of the automatic level sensor	[-]	tak
Removable control panel	[-]	tak
Possibility of external power supply to the machine	[-]	tak
Sensor for communication with other machines	[-]	tak
Internal oil filter	[-]	tak
Pressure control manometer	[-]	tak
Touch screen with remote control software	[-]	tak
USB port for operating a webcam	[-]	tak
Possibility to enable Mackma remote assistance	[-]	tak
Noise level	[dB]	72
Dimensions	[mm]	1980 x 1210 x 2200
Weight	[kg]	1400
