PIPE BENDING MACHINE - MACKMA BM34 SHANKLESS, BENDING Ø 33.4 - 38MM

Pipe and section bending machines - without mandrel

PIPE BENDING MACHINE - MACKMA BM34 SHANKLESS, BENDING Ø 33.4 - 38MM

25 958,00 zł net

Add to favorites

12 months of warranty

Contact with a trader:
Krzysztof Penkowski
E-mail: krzysztof.penkowski@eurometal.com.pl
Telefon: 603 400 333

MACKMA BM34 is the only mandrelless bending machine available on the market with the ability to bend pipes to the right and left. This is possible thanks to the use of a double-sided matrix holder. This innovative design allows for bending pipes with a diameter of up to 33.4 mm and a wall thickness of 3.38. The maximum bending radius in the pipe axis is 170 mm.

Quantity

Manual pipe clamping controlled by a knob with a counter - to guarantee the highest possible level of repeatability.

The bending speed is adjusted using an inverter in the range from 2 to 3 rpm. The modular structure of the bending die pin makes it possible to use tools from other manufacturers. The engine controlled by an inverter reduces electricity consumption to a minimum.

The bending machine is powered only by an electric motor - without hydraulic elements. This results in a low noise level and reduced operating costs.

To ensure long-term reliability, 100% of the components used in production are of Italian origin. The standard 2-year warranty is proof of the high quality of the machines.

Standard equipment:

easy-to-use control panel built into the body - EXPERT. Allows you to save up to 99 complete bending processes.
manual pipe clamp controlled by a knob with a counter
bending speed adjustable with an inverter
user manual in English
24 month warranty

Optional equipment (additionally paid):

set of left and right bending tools (bending die, pressure die and slides)
3 meter long pipe positioner
6 meter long pipe positioner
mechanical deburring device
holder for tools from other manufacturers
mobile control panel
precise wheels for free movement of the machine

Technical data	Unit	Value
Outer diameter of the pipe	[mm]	38
Bending radius	[mm]	170
Black steel pipe diameter when bent with a tensile force of 42 kg / mm2	[mm]	33.4
Pipe diameter for bending carbon steel with a tensile force of 35 kg / mm2	[mm]	38
Pipe diameter when bent made of stainless steel with tensile strength (AISI 304/316) 65 kg / mm2	[mm]	38,4 x 1,5
Torque	[N/m]	914
Working plate height h1	[mm]	180
Working plate length l1	[mm]	1
Bending angle	[°]	3
Bending direction	[-]	prawy i lewy
Supply voltage	[V]	220/230
Installed power	[kW]	0,55
Temperature range during operation	[°]	0-50
Device dimensions	[mm]	268x310x478
Weight	[kg]	34
