SOCO SB-127x2B-1S CNC pipe bender

Pipe and section bending machines - with mandrel

SOCO SB-127x2B-1S CNC pipe bender

1 183 333,20 zł net

Add to favorites

12 months of warranty

Contact with a trader:
Piotr Tymiński
E-mail: piotr.tyminski@eurometal.com.pl
Telefon: 603505252

SOCO 2B series hydraulic bending machines equipped with CNC control and servo motor drives for 2 axes. Operation is simple and intuitive, and the bending accuracy is very high.

Quantity

SOCO 2B series hydraulic bending machines equipped with CNC control and servo motor drives for 2 axes. Operation is simple and intuitive, and the bending accuracy is very high.

Main features of the device:

CNC controller with touch screen
Entering data in the YBC and XYZ system
Possibility to convert data from XYZ to YBC
Feed and rotation performed using servo motors - this solution is characterized by high reliability, precision and efficiency
Hydraulic bending arm equipped with an additional actuator supporting the bending process
Electrical system equipped with a cooling system
Automatic lubrication system for the mandrel increases its life as well as the quality and accuracy of bending
Automatic compensation of material elasticity
Smoothing die support
Spindle retraction programming function
The control panel is placed on a movable base, enabling the most favorable positioning for the operator

Main control features:

Operating system running under Windows
Mitsubishi servomotors that feed and rotate the pipe
Possibility to save programs on hard disk or FDD
Ability to store 30,000 files (up to 110 bends per pipe)
Possibility of 3D visualization of the bent model
Possibility to convert from YBC to XYZ and vice versa
Possibility of freely rotating the element on the display
Possibility to download monthly production

Optional software:

Ability to read AutoCAD files
Possibility of connecting to a measuring system and reading current machine parameters

Standard equipment:

NC control with touch screen
Early pin retraction system
Automatic pin lubrication system
Central lubrication system
Bending die support system
Portable control panel
User manual in English
CE declaration of conformity

Technical data	Unit	Value
Diameter of the bent pipe (steel)	[mm]	4.5 - 127
Diameter of the bent pipe (stainless steel)	[mm]	3 - 127
Tube length with mandrel	[mm]	5500
Single travel	[mm]	4000
Bending radius	[mm]	350
Bending angle	[°]	190
Bending speed	[°/sec]	18
Speed of setting movements	[°/s]	120
Feed speed	[mm/s]	7000
Bending accuracy	[°]	+/- 0,1
The accuracy of the positioning movements	[°]	+/- 0,1
Accuracy of the feed	[°]	+/- 0,1
Hydraulic pump motor power	[KM]	50
Actuating actuator power	[W]	3500
Power of the feed servo motor	[W]	5000
Dimensions	[mm]	7500x2400x2100
Weight	[kg]	9800
