Universal /manual lathes

UNIVERSAL LATHE EUROMET D460X1000

45 000,00 zł net
No rating
Add to favorites

12 months of warranty

Contact with a trader:
Piotr Tymiński
E-mail: piotr.tyminski@eurometal.com.pl
Telefon: 603505252

EUROMET D460X1000 universal lathe A lathe designed for small-lot production and working in tool shops or maintenance plants. The cast iron cast of the bed base guarantees very high rigidity and stability of the machine.

Quantity
Add to cart

EUROMET D460X1000 universal lathe A lathe designed for small-lot production and working in tool shops or maintenance plants. The cast iron cast of the bed base guarantees very high rigidity and stability of the machine.

  • the bed base is made of cast iron - one element
  • hardened bed guides
  • heat-treated spindle nose
  • hardened change gears in the spindle gear
  • the full range of threads can be machined
  • feed selection lock: by a screw or by a shaft
  • removable bridge

Standard equipment
  • 250mm 3-jaw lathe chuck
  • 4-jaw chuck 315mm
  • driving disc
  • steady rest
  • follow rest
  • thread indicator
  • digital readout for 2 axes
  • reduction sleeve MT 6/4
  • fixed tusk MT 4
  • cooling system
  • lighting
  • User manual in English
  • CE declaration of conformity

Optional equipment (paid additionally):
  • quick-change holder
  • ruler for cones
  • digital readout for 3 axes

Technical data Unit Value
Turning diameter over bed [mm] 460
Turning diameter over cross slide [mm] 274
Turning diameter in the bridge [mm] 690
Turning length [mm] 1000
Bed width [mm] 300
Spindle flight [mm] 58
Turning length in the bridge [mm] 155
Spindle tip [-] D1-6
Spindle seat [-] Morse 6
Spindle speed range [rpm/min] 25 - 2000
Maximum tool dimensions [mm] 25x25
Longitudinal feed range [mm/rpm] 0,031 - 1,7
Przesuw poprzeczny [mm] 285
Cross travel range [mm/rpm] 0,014 - 0,784
Metric thread [mm] 0,1 - 14
Inch thread [-] 2-112 T.P.I.
Modular thread [-] 0,1-7 M.P.
Thread D.P. [-] 4-112 D.P.
Tailstock sleeve diameter [mm] 60
Extend the tailstock quill [mm] 120
Tailstock sleeve tip [-] No.4 Morse
Engine power [kW] 4
Coolant pump power [kW] 0,1
Dimensions [mm] 2170x1040x1370
Weight [kg] 1720
