LATHE CNC TK 32S

104 356,35 zł 83 800,00 zł net
No rating
Add to favorites

12 months of warranty

Contact with a trader:
Magda Kyrcz
E-mail: magda.kyrcz@eurometal.com.pl
Telefon: 609504408

The TK 32S CNC lathe is designed for the processing of external and internal surfaces, it has the option of turning cones, making spherical surfaces (thanks to circular interpolation), as well as cutting all kinds of threads (cylindrical, conical, face). A Siemens 808D CNC control is used to control the lathe.

Quantity
Add to cart

The TK 32S CNC lathe is designed for the processing of external and internal surfaces, it has the option of turning cones, making spherical surfaces (thanks to circular interpolation), as well as cutting all kinds of threads (cylindrical, conical, face). A Siemens 808D CNC control is used to control the lathe. An inverter is used as the main drive, which ensures smooth regulation of the spindle speed in the entire range. The machine is available with a 6 position automatic tool head, a hydraulic lathe chuck and a hydraulic tailstock. The central lubrication system ensures proper operation of the ball screws and a long service life of the bed guides.

Equipment of the offered CNC lathe:
  • Siemens 808D control
  • 6-position tool head
  • 160 mm 3-jaw hydraulic chuck
  • Hydraulic tailstock
  • Cooling and lubrication system
  • LED work lamp
  • Emergency light
  • CE declaration
  • User manual in English

Technical data Unit Value
Turning diameter over bed [mm] 330
Turning diameter over slide [mm] 148
Workpiece length [mm] 700
X-axis travel range [mm] 190
Z axis travel range [mm] 750
Rotation speed [rpm/min] 3500
Spindle tip [-] D1-4
Spindle flight [mm] 38
Tool size [mm] 16x16
X / Z accelerated feed [m/min] 2,5/5
Extend the tailstock quill [mm] 120
Tailstock sleeve diameter [mm] 45
Tailstock taper [-] MT. 3
Main spindle motor [kW] 3
External dimensions L x W x H [mm] 1930x1140x2010
Net weight [kg] 650
