EUROMET WP100x2500 radial drilling machine
Priced individually
No rating
12 months of warranty
Contact with a trader:
Krzysztof Penkowski
E-mail: krzysztof.penkowski@eurometal.com.pl
Telefon: 603 400 333
Krzysztof Penkowski
E-mail: krzysztof.penkowski@eurometal.com.pl
Telefon: 603 400 333
EUROMET WP100x2500 radial drilling machine is used in factories, workshops and production lines in large factories. It is designed to perform the following operations: drilling, reaming, tapping, roughing, tapping, boring (option)
EUROMET WP100x2500 radial drilling machine is used in factories, workshops and production lines in large factories. It is designed to perform the following operations:
- drilling
- reaming
- drilling
- rough boring
- threading
- boring (option)
In addition, various types of accessories can be installed on the machine to expand the functionality and scope of processing.
The main features of the device:
- strong, rigid structure
- lighting large
- table working surface
- automatic spindle feed
- arm lifting and lowering motor
- mechanical clamping of the arm and headstock
- spindle micro-feed mechanism
Standard equipment:
- box table
- automatic spindle feed
- threading
- stepless speed control of the headstock with digital readout of the spindle speed (for the WP50 / 1600E model)
- lighting
- machine manual in English
- CE declaration of conformity
Optional equipment (additionally payable):
- quick-release chuck
- lubricator
- threading holder
| Technical data | Unit | Value |
|---|---|---|
| Drilling diameter in steel | [mm] | 100 |
| Distance from spindle axis to column | [mm] | 560 - 2560 |
| Headstock horizontal travel | [mm] | 2000 |
| Column diameter | [mm] | 600 |
| Distance from the spindle nose to the base working surface | [mm] | 700 - 2500 |
| Vertical arm travel | [mm] | 1300 |
| Arm rotation angle | [°] | +/- 360 |
| Spindle taper | [-] | MT6 |
| Rotational speed range | [rpm/min] | 8 - 1000 |
| Number of spindle speeds | [-] | 22 |
| Spindle feed value range | [mm/rpm] | 0,06 – 3,2 |
| Number of spindle feed values | [-] | 16 |
| Extend the spindle quill | [mm] | 500 |
| Main engine power | [kW] | 15 |
| Base dimensions (LxWxH) | [mm] | 3280x1630x330 |
| Drill dimensions (LxWxH) | [mm] | 3890x1630x4180 |
| Weight | [kg] | 19000 |
