PIPE LATHE EUROMET TR 340

Priced individually
No rating
Add to favorites

12 months of warranty

Contact with a trader:
Magda Kyrcz
E-mail: magda.kyrcz@eurometal.com.pl
Telefon: 609504408

Lathes of this type are used in the production of pipelines in the petrochemical industry, drilling pipes, in the steel industry and in the metallurgical industry. Thanks to the use of a spindle equipped with two handles and a CNC control, it is possible to cut internal and external threads with high precision.

Lathes of this type are used in the production of pipelines in the petrochemical industry, drilling pipes, in the steel industry and in the metallurgical industry. Thanks to the use of a spindle equipped with two handles and a CNC control, it is possible to cut internal and external threads with high precision.

Standard equipment:
  • 2 manual lathe chucks
  • main drive via servo motor
  • Fanuc 0i-TD control
  • cooling system
  • lighting of the processing area
  • machining space cover
  • chip container
  • manual tailstock with an extendable sleeve
  • central lubrication
Optional equipment (paid additionally):
  • control change to Sinumerik
  • electric or hydraulic operated handles
  • steady rest
  • follow rest
  • tusk standing
  • rotating canine
  • extra jaws

Technical data Unit Value
Diameter above the bed [mm] 1000
Length of the workpiece in centers [mm] 1000
The hole in the spindle [mm] 350
Pipe diameter in the spindle [mm] 340
Distance of the spindle axis to the guides [mm] 500
Bed width [mm] 755
The size of the knife [mm] 45x45
Number of tool post [pcs] 4
Number of handles [pcs] 2
Rotational speed range [rpm/min] 8 - 255
X axis accelerated feed [m/min] 6
Z axis accelerated feed [m/min] 6
X axis travel [mm] 550
Z axis travel [mm] 1000
Main drive servo motor [kW] 22
Dimensions [mm] 4100x2600x2400
Weight [kg] 12000
