Manual band saw IMET GBS 242 GH Auto Cut enabling cutting at an angle - arm torsion to the right and left - and hydraulic feed. The machine is equipped with a manual vice with quick clamping, manual lifting of the arm, cooling system, two cutting speeds and smoothly adjustable feed. Cutting tool - bimetallic strip, height 27 mm, is precisely guided in cubes made of sintered carbides.
Quantity
Add to cart
Manual band saw IMET GBS 242 GH Auto Cut enabling cutting at an angle - arm torsion to the right and left - and hydraulic feed. The machine is equipped with a manual vice with quick clamping, manual lifting of the arm, cooling system, two cutting speeds and smoothly adjustable feed. Cutting tool - bimetallic strip, height 27 mm, is precisely guided in cubes made of sintered carbides.
Basic data:
- Manual machine scissor type
- Maximum cutting diameter: ø 250 mm
- Working feed: gravitational arm drop; smooth adjustment
- Arm lifting: manual
- Miter cut: right 0° - 45° - 60°; to the left - 45°
- Cutting band size: 2965 x 27 x 0.9mm
- Belt speed: 2 cutting speeds 35/70 m/min
- Vice: manual - quick clamp
GBS 242 GH ma duży blat roboczy z obrotowym zintegrowanym z pałąkiem zaprojektowanym tak, aby uniknąć nacięć na tym samym łożysku kulkowym w celu łatwego obracania.
Imadło z regulowanymi prowadnicami, przesuwające się poprzecznie po powierzchni roboczej i szybkim podejściem do ciętego materiału.
Prowadnice ostrza modelu GBS 242 GH są wyposażone we wkładki z węglików spiekanych i dodatkowe łożyska przednie dla optymalnego ustawienia ostrza.
Bimetalowe ostrze ma wymiary 2965 x 27 x 0,9 mm i pracuje z prędkością od 35 do 70 metrów na minutę, co czyni go idealnym narzędziem do obróbki stali i żeliwa.
System kontrolowanego opuszczania jest wyposażony w automatyczną obsługę z 3-pozycyjnym selektorem dla:
- Manual cutting
- Quick approach to the material
- Automatic cutting with autonomous lowering, adjustable stop and end-cut microswitch
| CUTTING ANGLE |
|
|
|
|
0° |
250 |
290x210 |
210 |
|
45° P |
220 |
210x200 |
200 |
|
60° P |
140 |
140x130 |
130 |
|
45° L |
170 |
170x170 |
170 |
|
0 ° for solid material (C45) |
150 |
|
|
Standard equipment:
- cooling system
- bimetallic tape - 1 piece in the machine
- english user manual
- CE certificate
Additional equipment at an extra charge:
- roller feeders
- measure with bumper
- connector
- oil mist lubrication system (micronizer)
- Strain gauge for precise adjustment of belt tension
| Technical data | Unit | Value |
|---|---|---|
| The width of the cutting band | [mm] | 27 |
| Vise opening width | [mm] | 290 |
| The dimensions of the cutting band | [mm] | 2965×27×0,9 |
| Cutting band speed | [m/min] | 35/70 |
| Cutting band motor power | [kW] | 1.1/1.3 |
| Working height | [mm] | 940 |
| Dimensions | [mm] | 1500x1250x1700 |
| Weight | [kg] | 290 |
