TRAINING LATHE EUROMET VD250X550

13 297,00 zł 12 796,00 zł net
No rating
Add to favorites

12 months of warranty

Contact with a trader:
Piotr Tymiński
E-mail: piotr.tyminski@eurometal.com.pl
Telefon: 603505252

The VD250x550 universal mini lathe is a machine of small dimensions, with electronically controlled rotation speed, easy to use with intuitive adjustments. It has a wide range of possible works, it can perform external, internal, face and final turning. It is equipped with the possibility of cutting both metric and inch threads. It can be used both in home workshops and for small works in company workshops. An excellent lathe for training in a profession in schools, institutes and other positions where precision and speed of production of details and repair of other devices is essential.

Quantity
Add to cart

The VD250x550 universal mini lathe is a machine of small dimensions, with electronically controlled rotation speed, easy to use with intuitive adjustments. It has a wide range of possible works, it can perform external, internal, face and final turning. It is equipped with the possibility of cutting both metric and inch threads. It can be used both in home workshops and for small works in company workshops. An excellent lathe for training in a profession in schools, institutes and other positions where precision and speed of production of details and repair of other devices is essential.

Standard equipment:
  • 3-jaw lathe chuck
  • Stepless speed regulation
  • Metal base with built-in drawers and a tool cabinet
  • Spindle cover
  • Lead screw cover
  • Machine manual in English
  • CE declaration of conformity

Technical data Unit Value
Turning diameter over bed [mm] 250
Turning length [mm] 550
Spindle flight [mm] 38
Spindle speed range [rpm/min] 125 - 2000
Spindle bore cone [-] MT3
Maximum tool dimensions [mm] 0,20-3,5(18 wartości)
Longitudinal feed range [mm] 0,1 - 0,2
Transverse travel [mm] 420
Cross travel range [mm/rpm] 0,07 - 0,52
Metric thread [mm] 0,4-3,0
Inch thread [-] 10-44 T.P.I.
Extend the tailstock quill [mm] 80
Tailstock sleeve tip [-] MT2
Engine power [kW] 1
Tool post travel [mm] 230
Dimensions [mm] 1180x640x570
Weight [kg] 145
