Square column drilling machines

EUROMET WK50 hull drilling machine

36 750,00 zł net
No rating
Add to favorites

12 months of warranty

Contact with a trader:
Magda Kyrcz
E-mail: magda.kyrcz@eurometal.com.pl
Telefon: 609504408

The EUROMET WK50 frame drilling machine is a universal machine that can be used to process workpieces in a wide range of dimensions and made of various materials. The WK50 series frame drilling machines are characterized by high rigidity ensuring high accuracy of making holes. These drills are used in locksmith shops, repair shops and in the production line etc.

Instrukcja obsługi: wiertarka kadłubowa EUROMET WK50
Add to cart

150,00 zł

* applies to instruction
Quantity
Add to cart

The EUROMET WK50 frame drilling machine is a universal machine that can be used to process workpieces in a wide range of dimensions and made of various materials. The WK50 series frame drilling machines are characterized by high rigidity ensuring high accuracy of making holes. These drills are used in locksmith shops, repair shops and in the production line etc.
They are designed to perform the following operations:
  • drilling
  • front dredging
  • reaming
  • drilling
  • threading

Standard equipment:
  • Variable spindle speed through gears
  • Automatic headstock feed
  • Mechanical headstock feed
  • Cooling system
  • A set of tools for operating the machine
  • Reduction sleeves 4 pcs.
  • Drilling depth stop
  • Workspace lighting
  • A table with dimensions of 560x480 mm
  • CE declaration
  • User manual in English

Technical data Unit Value
Drilling diameter [mm] 50
Torque [Nm] 350
Main spindle taper [-] MT5 Morse
Extend the spindle sleeve [mm] 250
Headstock travel [mm] 200
Distance from the spindle axis to the column surface [mm] 335
Spindle speed (12 values) [rpm/min] 31.5 - 1600
Feed values (9 values) [mm/rpm] 0,056 - 1,80
Working table surface [mm] 560x480
Distance from the spindle to the surface of the worktable [mm] 830
Working table travel [mm] 300
The working surface of the base [mm] 650x550
Main engine power [kW] 4
Dimensions [mm] 1090x905x2535
Weight [kg] 1250
